21031238 副变幅力限器组件

21031238 副变幅力限器组件

1 A210111000204 bolt M12×40GB5783 10.9 grade 8
2 A210401000002 Washer 12GB93 8
3 21031236 Baffle 4
4 21012464 Connection board 4
5 21032278Connection plate 4
6 21012138 Pin Pin 2
7 10115355 pin 2
8 10140566 pin 2
9 A210491000043 pin 8×140GB91 2
10 21016804 single connection board 2

21031239 副臂力限器组件

1 A210111000204 bolt M12×40GB5783 10.9 grade 8
2 A210401000002 Washer 12GB93 8
3 21031236 Baffle 4
4 21019039 Double connection board 4
5 21012138 Pin Pin 4
6 10115355 pin 4
7 10140566 pin 2
8 A210491000043 pin 8×140GB91 2
9 21016804 single connection board 2
10 A210111000080 bolt M6×20GB5783 2
11 A210401000016 Washer 6GB93 2
12 10456217 Wiring harness fixing bracket 2
