10219114 辅助液压系统

10219114 辅助液压系统

1 B230103003552 hose Q/SY1102 2
2 B230103007976 hose Q/SY1102 2
3 21026636 pipe joint 6
4 B229900003544 quick connector male connector 4
5 B229900003543 quick connector female connector 4
6 B290000001238 dust cap female connector 4
7 B290000001241 dust cap male connector 4
8 21002847 pipe joint 2
9 10508813 Steel pipe assembly 2
10 10349874 Auxiliary installation cylinder 1
11 A220401000469 balancing valve 3
12 21005041 pipe joint 2
13 21009115 Hard pipe assembly 1
14 21033114 Hard pipe assembly 1
15 10505928 Steel pipe assembly 2
16 21021532 pipe joint 1
17 A229900003506 pipe joint 1
18 21027304 pipe joint 1
19 B230103005314 hose Q/SY1102 1
20 21002815 pipe joint 1
21 21007930 pipe joint 8
22 A229900002895 pipe joint 2

23 21002955 pipe joint 2
24 21033121 Cab tilt cylinder 50/25/150 2
25 A210770000616 pipe joint 6
26 B230103000447 hose 2SN8-DKOL-400Q/SY1102 2
27 21083669 Test connector 5
28 A229900002938 pipe joint 5
29 B230103000443 hose Q/SY1102 1
30 B220401000756 Balance valve 1
31 21002819 pipe joint 4
32 B210851000003 single pipe clamp 33
33 10184203 Steel pipe assembly 2
34 21026633 pipe joint 1
35 21029688 Pipe joint 1
36 B230103000690 hose Q/SY1102 2
37 21022350 pipe joint 5
38 10351471 Main luffing mast left lever cylinder 2
39 A229900002559 pipe joint 8
40 B230103000335 hose Q/SY1102 2
41 A229900002812 pipe joint 1
42 B230103000111 hose Q/SY1102 2
43 A229900002542 pipe joint 1
44 B230103000102 hose Q/SY1102 1

45 B230103000461 hose Q/SY1102 1
46 B230103000451 hose Q/SY1102 1
47 B230103001439 hose Q/SY1102 2
48 10349873 Main boom root section power pin cylinder 2
49 B230103000443 hose Q/SY1102 2
50 A229900006319 Quick connector 3
51 A229900006320 Quick connector 3
52 60007741 Dust cap Cap-FIRG-F-1/4 3
53 60007744 Dust cap Cap-FIRG-M-1/4 3
54 B230103000655 hose Q/SY1102 1
55 21002845 pipe joint 4
56 A229900002533 pipe joint 5
57 21002822 Pipe joint 1
58 10186023 Guide shaft 4
59 21051125 bolt M24×65GB5783 10.9 level 4
60 10186024 Baffle 2
61 A210307000009 Nut M30GB6170 Level 10 4
62 10186025 Protection slot 4
63 21011029 pipe joint 2
64 A210204000320 screw M8×40GB70.1 10.9 level 12
65 21002850 pipe joint 2
66 21005527 pipe joint 2

67 B230103003138 hose Q/SY1102 1
68 21003010 pipe joint 2
69 10186026 Steel pipe assembly 2
70 B230103000462 hose Q/SY1102 2
71 21000745 test connector 1
72 21040370 Diversion block 1
