10170957 覆盖件

10170957 覆盖件

1 10170958 Rear cover assembly 1
2 10170970 Left middle cover assembly 1
3 10170974 Right middle cover assembly 1
4 10170976 Front cover 1
5 10170977 Saddlebag assembly 1 1
6 10171076 saddlebag assembly 4 1
7 10170981 Saddlebag assembly 2 1
8 10170965 Ladder 2
9 10170985 Saddlebag assembly 3 1
10 10355022 Electric control cabinet bracket 5
11 A210111000199 bolt M12×20GB5783 10.9 level 4
12 A210405000001 gasket 12GB97.1 24
13 A210111000101 bolt M12×25GB5783 10.9 level 8
14 10478004 battery bracket 1
15 A210307000001 Nut M12 GB6170 8
16 A210111000202 Bolt 12
17 21025775 pin 4
18 10124817 pin 4
