10181068 Fuel system

10181068 Fuel system

1 10180795 fuel tank 1
2 A210111000053 bolt M16×40GB5783 10.9 level 4
3 A210401000004 Washer 16GB93 4
4 21001338 Washer 16GB97.1 300HV 4
5 10181057 Bracket Q400C.20(a).2.2 2
6 A229900001347 hose hoop φ16-φ25QC619 2
7 A210111000012 bolt M10×20GB5783 10.9 level 4
8 A210401000001 Washer 10GB93 4
9 A210405000011 gasket 10GB97.1 4
10 A229900008855 Double pipe clamp 4
13 A210111000202 Bolt 4
14 A210405000001 gasket 12GB97.1 8
15 A210401000002 gasket 12GB93 8
16 21011844 connector 2
17 21011845 Washer 2
18 10180801 oil pipe 1
19 21011848 connector 2
20 21011849 Washer 2
21 10180997 oil pipe 1
22 10181005 Oil pipe Q400C.20(a).2.6 1
23 10181007 oil pipe 2
25 10181022 steel pipe 1

26 10181024 steel pipe 1
27 A229900002420 single pipe clamp 12
28 10181061 Oil pipe Q400C.20(a).2.10 1
29 10181064 oil pipe 1
30 A210111000101 Bolt M12×25GB5783 10.9 Level 4
