21037182 张紧轮总成 21037182 Tension pulley assembly 21037182 张紧轮总成

21037182 Tension pulley assembly

1 21028426 Tension pulley 1
2 21020803 pin 2
3 10141075 Bushing 2
4 10141076 axis 1
1 21028426 Tension pulley 1
2 21020803 pin 2
3 10141075 Bushing 2
4 10141076 axis 1

21028842 Traveling counterweight assembly

1 10078797 Baffle 2
2 21028844 flange shaft 2
3 21028843 Counterweight 2
4 A210111000062 bolt M20×60GB5783 10.9 level 8
5 A210406000014 Washer 20GB97.1 300HV 8
6 A210111000204 bolt M12×40GB5783 10.9 level 8
1 10078797 Baffle 2
2 21028844 flange shaft 2
3 21028843 Counterweight 2
4 A210111000062 bolt M20×60GB5783 10.9 level 8
5 A210406000014 Washer 20GB97.1 300HV 8
6 A210111000204 bolt M12×40GB5783 10.9 level 8
