21011765 Base assembly

21011765 Base assembly

1 21032985 Lower leg assembly 2
2 21011761 Pin Pin 4
3 21011736 Connecting frame assembly 4
4 10124817 pin 4
5 21011716 Upper leg assembly 2
6 21011676 pad 4
7 A210111000024 bolt M10×30GB5783 10.9 level 12
8 21011746 Feet assembly 4
9 21011762 Pin Pin 8
10 21011681 Pin 4
11 10076425 pin 4
12 21011682 Base weldment 1
13 21011677 Leg pin 4
14 21011678 pad 4
15 21011674 Bent pin 4
17 21011763 Pin Pin 4
18 21011764 Omnidirectional level 1
19 A210111000122 bolt M4×12GB5783 3
20 A210401000013 Washer 4GB93 3

21011746 支脚总成

1 A210491000017 pin 4×40GB91 1
2 21011756 Latch assembly 1
3 21011747 Leg 1
1 A210491000017 pin 4×40GB91 1
2 21011756 Latch assembly 1
3 21011747 Leg 1
