零件代码 PART NUMBER |
名称 PART NAME |
|
|
60093151 |
配油盘 |
Plate, port |
|
60151387 |
配油盘 |
Plate, port |
|
60008550 |
盖 |
Cover |
|
60008511 |
盖 |
Cover |
|
60008543 |
内六角螺栓 |
Bolt, socket head |
|
60039371 |
内六角螺栓 |
Bolt, socket head |
|
60008722 |
铆钉 |
Rivet |
|
60008717 |
螺栓 |
Bolt, socket head |
|
60008725 |
堵 |
Plug |
|
60038547 |
铭牌 |
Nameplate |
|
60008530 |
销 |
Pin |
|
60008518 |
活塞 |
Piston |
|
60008521 |
挡板 |
Plate, retaining |
|
60008542 |
挡板 |
Plate, retaining |
|
60008501 |
套 |
Sleeve |
|
60008549 |
销 |
Pin |
|
60008693 |
O形圈 |
O-ring |
|
60008695 |
O形圈 |
O-ring |
|
60008691 |
O形圈 |
O-ring |
|
60008544 |
螺柱 |
Stud |
|
零件代码 PART NUMBER |
名称 PART NAME |
|
|
60008742 |
螺柱 |
Stud |
|
60008705 |
O形圈 |
O-ring |
|
60038330 |
吊环螺栓 |
Eyebolt |
|
60151388 |
油封 |
Seal |
|
60039326 |
挡圈 |
Ring |
|
60039325 |
挡圈 |
Ring, Retainer |
|
60038452 |
六角螺母 |
Nut |
|
60039359 |
六角螺母 |
Nut |
|
60008723 |
挡圈 |
Ring, retaining |
|
60008737 |
销 |
Pin |
|
零件代码 PART NUMBER |
名称 PART NAME |
|
|
60008508 |
阀杆 |
Stem, valve |
|
60008493 |
阀座 |
Seat, valve |
|
60008523 |
挡圈 |
Ring, retaining |
|
60008500 |
弹簧 |
Spring |
|
60008496 |
调节螺杆 |
Screw, adjusting |
|
60008505 |
螺母 |
Nut |
|
60008512 |
机体 |
Body |
|
60008552 |
齿轮 |
Gear, drive |
|
60008581 |
齿轮 |
Gear, driven |
|
60008491 |
滤芯 |
Filter |
|
60008509 |
机体 |
Cover |
|
60008730 |
螺钉 |
Bolt |
|
60008731 |
螺钉 |
Bolt |
|
60008729 |
螺钉 |
Screw |
|
60008873 |
垫圈 |
Washer |
|
60008504 |
垫圈 |
O-ring |
|
60008736 |
销 |
Pin |
|
B230101000047 |
O形圈 |
O-Ring-10.8 |
|
B230101000229 |
O形圈 |
O-ring |
|
零件代码 PART NUMBER |
名称 PART NAME |
|
|
60118638 |
螺栓 |
Stud |
|
60118639 |
销 |
Pin |
|
60008546 |
销 |
Pin |
|
60118637 |
螺母 |
Nut |
|
60008698 |
O形圈 |
O-ring |
|
60008697 |
O形圈 |
O-ring |
|
60008702 |
O形圈 |
O-ring |
|
A210609000036 |
O形圈 |
O-ring |
|
60008708 |
O形圈 |
O-ring |
|
60008694 |
O形圈 |
O-ring |
|
60118625 |
盖 |
Cover |
|
60118643 |
柱塞 |
Spool |
|
60118631 |
阀套 |
Valve, sleeve |
|
60193177 |
弹簧 |
Spring |
|
60118636 |
活塞 |
Piston |
|
60118640 |
支座 |
Valve, seat |
|
60155069 |
调节杆 |
Rod, adjusting |
|
60118630 |
密封 |
Spring, seat |
|
60118634 |
堵头 |
Plug |
|
60118644 |
杠杆 |
Lever |
|
零件代码 PART NUMBER |
名称 PART NAME |
|
|
60118627 |
机体 |
Body, regulator |
|
60119019 |
钢球 |
Ball |
|
60118635 |
阀座 |
Valve, seat |
|
60118629 |
密封 |
Seal |
|
60008728 |
紧定螺钉 |
Screw, set |
|
60008724 |
堵 |
Plug |
|
60150556 |
螺钉 |
Bolt |
|
60150559 |
螺钉 |
Bolt |
|
A210204000217 |
螺钉M6×40GB70.1 10.9级 |
Bolt |
|
60018102 |
螺栓 |
Bolt |
|
60038565 |
内六角螺栓 |
Bolt, socket head |
|
60118626 |
机体 |
Cover |
|
60119020 |
单向阀组件 |
Valve GP, check |
|
60081917 |
比例减压阀 |
Valve, proportional reducing |
|
零件代码 PART NUMBER |
名称 PART NAME |
|
|
60008713 |
堵 |
Plug |
|
60100505 |
弹簧盖 |
Cap, pilot |
|
60100498 |
直线行走阀芯 |
Spool, valve, straight travel |
|
60008819 |
螺柱 |
Bolt, socket head |
|
60008823 |
座 |
Seat |
|
60100503 |
弹簧 |
Spring |
|
60100502 |
弹簧 |
Spring |
|
60008818 |
挡圈 |
Ring, retaining |
|
60008789 |
盖 |
Cap |
|
60008721 |
内六角螺钉 |
Bolt, socket head |
|
60100514 |
O形圈 |
O-ring |
|
60050051 |
O形圈 |
O-ring |
|
60008700 |
O形圈 |
O-ring |
|
零件代码 PART NUMBER |
名称 PART NAME |
|
|
60100505 |
弹簧盖 |
Cap, pilot |
|
60100501 |
左行走阀芯 |
Spool, valve, travel |
|
60008819 |
螺柱 |
Bolt, socket head |
|
60008823 |
座 |
Seat |
|
60008770 |
弹簧 |
Spring |
|
60008769 |
弹簧 |
Spring |
|
60008818 |
挡圈 |
Ring, retaining |
|
60008789 |
盖 |
Cap |
|
60008721 |
内六角螺钉 |
Bolt, socket head |
|
60100514 |
O形圈 |
O-ring |
|
60050051 |
O形圈 |
O-ring |
|
零件代码 PART NUMBER |
名称 PART NAME |
|
|
60008721 |
内六角螺钉 |
Bolt, socket head |
|
60100505 |
弹簧盖 |
Cap, pilot |
|
60100479 |
动臂阀芯 |
Spool, valve, boom |
|
60008819 |
螺柱 |
Bolt, socket head |
|
60008823 |
座 |
Seat |
|
60008770 |
弹簧 |
Spring |
|
60008769 |
弹簧 |
Spring |
|
60008818 |
挡圈 |
Ring, retaining |
|
60008789 |
盖 |
Cap |
|
60100514 |
O形圈 |
O-ring |
|
60050051 |
O形圈 |
O-ring |
|
零件代码 PART NUMBER |
名称 PART NAME |
|
|
60008819 |
螺柱 |
Bolt, socket head |
|
60008823 |
座 |
Seat |
|
60008770 |
弹簧 |
Spring |
|
60008769 |
弹簧 |
Spring |
|
60008818 |
挡圈 |
Ring, retaining |
|
60008721 |
内六角螺钉 |
Bolt, socket head |
|
60100505 |
弹簧盖 |
Cap, pilot |
|
60100474 |
铲斗阀芯 |
Spool, valve, bucket |
|
60100469 |
盖 |
Cap |
|
60100509 |
活塞 |
Spool |
|
60100468 |
堵 |
Plug |
|
60100514 |
O形圈 |
O-ring |
|
60050051 |
O形圈 |
O-ring |
|
60008705 |
O形圈 |
O-ring |
|
零件代码 PART NUMBER |
名称 PART NAME |
|
|
60008819 |
螺柱 |
Bolt, socket head |
|
60008823 |
座 |
Seat |
|
60008770 |
弹簧 |
Spring |
|
60008769 |
弹簧 |
Spring |
|
60008818 |
挡圈 |
Ring, retaining |
|
60008721 |
内六角螺钉 |
Bolt, socket head |
|
60100505 |
弹簧盖 |
Cap, pilot |
|
60100482 |
斗杆阀芯 |
Spool, valve, arm |
|
60008789 |
盖 |
Cap |
|
60100514 |
O形圈 |
O-ring |
|
60050051 |
O形圈 |
O-ring |
