SY215C9 hydraulic excavator SANY ACW



A820205002283

Fitting

B210780000024

Fitting, Elbow

B210780001426

Fitting

10137010

Fitting

B220401000916

Valve AS, drain

60006360

Washer, copper

A229900001345

Clamp

10192981

Hose, return

A820205002483

Fitting

A831233105800

Hose AS, grease

60083322

Clamp

A210111000199

Bolt

B229900000686

Grease nipple








60180834

回转马达    Motor AS, swing

60180835

回转减速机    Drive AS, swing

B229900003185

20T回转机构维修包    Kit, seal, swing motor








60008573

Shaft, motor output

60008571

Housing, swing motor

60008740

Bearing

60008744

Seal

60008881

O-ring

60008883

O-ring

B229900003186

Plate, seperator

B229900003187

Plate, friction

B220401000688

Valve,brake,delay

60008845

Bolt, socket head








B229900002240

Piston AS

60008580

Piston

60008574

Slipper

60008570

Valve, body GP

60008569

Valve, body

60008878

Pin

60008575

Cylinder

60008567

plate

60008572

Plate

60008577

Swashplate

B229900002241

Plate, port

60008579

Body, check valve

60008578

Spring

60008722

Rivet

60008840

Bolt, socket head

60008739

Bolt

60008716

Plug

60008882

O-ring

60008862

O-ring

60008576

Brake, piston








60008568

弹簧    Spring

B220401000693

20T回转溢流阀    Valve, relief

B230101000036

O形圈    O-ring








B220401000687

Anti-swing Valve of rotary motor

60008793

Valve, body

60008711

Plug

B230103003795

O-Ring

60008699

O-ring

60008707

O-ring

60008848

Bolt, socket head

60008753

Valve, anit-rebound

B230101000363

O-ring

60008867

Ring, retainer








60065327

Housing, lower

60065314

Gear, pinion

60065240

Gear, ring

B221500000627

Bearing, self-aligning

B221500000626

Bearing, self-aligning

A210204000297

Bolt, socket head

60065353

Seal, oil

B230101001021

Seal, grease








60065230

Gear, planet

60065228

Gear, sun

60065229

Gear, planet

60065227

Gear, sun

60065319

Carrier, planet gear

60065318

Plate, carrier

60065226

Bearing, shaft AS

60008608

Shaft

60008616

Washer

B229900002800

Washer, thrust

60065255

Washer ,thrust

60008605

Dipstick, oil

60008614

Tube, dipstick

60008615

Tube, fill

B229900002437

Cap, breather

60008727

Bushing

60008875

Ring, snap

60008876

Ring, snap








60081915

Pump GP, piston

60000735

Pump, gear, pilot

60193167

Regulator, main pump

60204222

Pump, main, seal kit








60008878

Pin

60008528

Shaft, drive

60008527

Shaft, driven

60008492

Coupling

60006940

Bearing, front

60008726

Bearing

60008582

Seal

B229900005459

Barrel AS

60008519

Piston

60008517

Slipper

60008516

Ring

B229900005452

Bushing, spherical

60008545

Spring

B229900005449

Support, swashplate

B229900005455

Swashplate

60008732

Bushing

B229900005456

Head

60008531

Plate, bearing

60039298

Body

60039372

Housing, center
