SY215C9 hydraulic excavator SANY AVC



B210780000244

Flange, Split

A210204000354

Screw

B230103002316

Hose AS

B230103002317

Hose AS

A810406012423

Bracket, upper

A810406012424

Bracket, lower

A210204000357

Bolt

A820606010360

Grommet








A210204000215

Screw

B230101000456

O-ring

11538576

Tube group

11538578

Tube group

11539353

Clamp

A820606010360

Grommet

24000639

Washer

A210204000337

Bolt

A210204000355

Screw

11539135

Tube, boom cylinder, head end

11539237

Tube, boom cylinder, rod end

11654944

Clamp AS

B210780000696

Flange, Split

A210204000354

Screw

B230103002294

Hose AS










B210780000244

Flange, Split

A210204000354

Screw

A210204000215

Screw

B230101000456

O-ring

11531616

Tube group

60041191

Hose AS

60065987

Hose AS

11144202

Bracket

A210204000354

Screw

24000637

Washer

11160698

U type bolt

A210307000036

Nut

60060546

Washer








B210780000244

对开法兰    Flange, Split

A210204000354

螺钉 M10×30GB70.1 10.9级    Screw

60032054

胶管    Rubber Hose








B210780000244

Flange, Split

A210204000354

Screw

B230103002318

Hose AS

B230103002320

Hose AS

A820606010360

Grommet

A810406012423

Bracket, upper

A810406012424

Bracket, lower

A210204000357

Bolt








B210780000244

Flange, Split

A210204000354

Screw

60167468

Hose AS

60167467

Hose AS

A820205002474

Fitting

B230101000356

O-Ring-23.7

13186696

Connector

13186692

Tube, fill

60263201

Cap, breather

B229900006314

Reducer AS

A210111000062

Bolt

A210491000132

Washer

A820301012852

Pin, dowel








60078309

胶管    Hose AS

B210780000244

对开法兰    Flange, Split

A210204000354

螺钉 M10×30GB70.1 10.9级    Screw








60123319

Plunger Pump

A210204000300

Bolt, socket head

A210491000132

Washer

B210780000004

Flange, Split

A210204000462

Screw

60273783

Hose AS

B210780000244

Flange, Split

A210204000354

Screw

60284989

Hose AS

60318588

Valve, main control

A210111000203

Bolt

A210204000198

Bolt, socket head

A210111000212

Bolt

60060553

Washer

13665281

Bracket, mounting

A210110000324

Bolt








B230103001168

Hose AS

B230101000356

O-Ring-23.7

A820205000187

Fitting

13623327

Tube, suction

B230101000038

O-Ring-69.4

A210204000337

Bolt

24000639

Washer

13623847

Tank, hydraulic

60129702

Valve, breather AS

A210204000130

Screw

24000632

washer

B230101000366

O-ring

13623276

Hose

60250343

Clamp, hose

A210204000198

Bolt, socket head

A820101118172

Spacer

A210491000118

High-strength steel washer

13657741

Tube, return








11539370

Clamp

11539392

U type bolt

A210307000012

Nut

60060565

Washer

11160698

U type bolt

A210307000036

Nut

60060546

Washer

11539375

Tube group

60000846

O-ring
