SY335C9I2KH hydraulic excavator SANY SGE



零件代码 PART NUMBER

名称 PART NAME

60008879

弹簧销

Pin, roll

60008604

调整螺母

Nut, adjusting

60008809

圆板

Plate, circular

60008602

接头

Shaft

60008603

密封圈

Ring, seal

60008595

堵头

Plug

B230101000363

O形圈

O-ring

60008599

推动杆

Rod

60008811

Plate

60008758

弹簧座

Seat, spring

60008775

弹簧

Spring

60008597

垫圈

Washer

60008774

弹簧

Spring, large

60008760

滑轴

SPOOL

60008795

壳体

Housing

60008799

O形圈

O-ring

60008810

油口接板

Plate, connecting

60008786

内六角螺钉

Bolt, socket head

60008598

密封垫圈

Washer, seal

60008806

衬套

Sleeve








零件代码 PART NUMBER

名称 PART NAME

60331163

手动先导阀维修包    Kit, seal








零件代码 PART NUMBER

名称 PART NAME

A820205000836

M24-M26接头

Connector

A229900001581

O形圈

O-ring 21.7×3.5(JISB2401)

A820205000839

接头

Fitting

A230101000247

O形圈

O-ring 10.9×2.3(JISB2401)

60000307

胶管

Rubber hose

B230103002135

胶管

Rubber Hose

A820205000945

G1-M30接头

Connector

B230101000050

O形圈

O-ring

A820205000962

接头

Connector

B230101000090

O形圈

B230101000090

B230103000975

胶管

Hose Assembly

A820205000940

接头

Fitting

B230101000047

O形圈

O-Ring-10.8

B230103001258

胶管

Rubber hose

B230103001022

胶管

Rubber Hose

B210780000024

直角组合接头

Fitting, Elbow

A820205000961

G3/8-M18接头

Connector

B230101000049

O形圈

O-ring

A820205000947

堵头

G3/8 jam-SY200A.1.4.3-5

A820205001771

堵头

Screw Plug








零件代码 PART NUMBER

名称 PART NAME

B230103004375

胶管

Rubber Hose

60136331

六联电磁换向阀组

Solenoid valve group

A210204000345

螺钉M10×70GB70.1 10.9级

Bolt

A210491000120

垫圈

washer

B210780000028

直角组合接头

Fitting, Elbow

60265303

隔膜式蓄能器

Accumulator

B210780000170

管接头

Fitting

B210780000827

管接头

Fitting

B210780000016

三通组合L型接头

Fitting, Tee

B210780001310

直角组合接头

Fitting, Elbow

B210780001007

三通组合L型接头

Fitting, Tee

A820205000838

接头

Fitting

A230101000243

O形圈

O-ring 16.7×3.5(JISB2401)

10077549

接头

Fitting

A820205001144

M33-M30接头

Connector

B230101000036

O形圈

O-ring

B210780000018

三通组合L型接头

Fitting, Tee








零件代码 PART NUMBER

名称 PART NAME

60065224

电磁切换阀    Solenoid, valve on/off

60065222

减压阀KDRDE5K-31/30C50-122(    Solenoid, proportional








零件代码 PART NUMBER

名称 PART NAME

B230103000914

胶管

Rubber hose 1SN6-DKOL-

B230103001359

胶管

Hy hose 1SN6-DKOL-DKOL90-

B230103000808

胶管

Tube

A210110000437

螺栓M12×65GB5782 10.9级

Bolt M12×65GB5782 Grade 10.9

B230103000992

胶管

Rubber Hose

B230103000993

胶管

Hose AS

A831213050000

胶管

Hose AS

B230103000977

胶管

Hose AS

B230103002045

胶管

Hose AS

10237402

继电器防护板

Protective plate of relay

10077269

过渡块

Transitional block

B210780000172

管接头

Fitting

11415538

过渡块板

Transitional Plate

B230103004133

胶管

Hose AS

B210780000170

管接头

Fitting

A820205000940

接头

Fitting

B230103001947

胶管

Hy hose 1SN6-/SY1102








零件代码 PART NUMBER

名称 PART NAME

B230103002657

胶管

Hose AS

A820205001061

负流量传感器接头

Negative Flowrate Sensor

B220400000169

三通梭阀

Valve, shuttle, tee

B210780001045

管接头

Fitting

A820205000947

堵头

G3/8 jam-SY200A.1.4.3-5

B230103003046

胶管

Rubber Hose

A831213035000

胶管

Rubber hose

A820205000940

接头

Fitting

B230101000047

O形圈

O-Ring-10.8

B230101000049

O形圈

O-ring

A820205000946

接头

Fitting

B210780000418

管接头

Fitting

A820205001771

堵头

Screw Plug








零件代码 PART NUMBER

名称 PART NAME

A820205000942

接头

Fitting

B230101000356

O形圈

O-Ring-23.7

A820205000941

接头

Connector, straight

B230101000090

O形圈

B230101000090

A820205000940

接头

Fitting

B230101000047

O形圈

O-Ring-10.8

B210780000170

管接头

Fitting

B230103001239

胶管

Rubber hose

B230103002446

胶管

Hydraulic Hose Assembly

21033030

胶管

Hydraulic Hose Assembly2SN10-

A831213035000

胶管

Rubber hose

21018549

胶管

Rubber Hose

B210780000418

管接头

Fitting

B210780000016

三通组合L型接头

Fitting, Tee

B210780000827

管接头

Fitting

11213443

先导滤支架

Pilot filter bracket

24000511

垫圈8GB93 达克锈

Washer

A210204000340

螺钉M8×16GB70.1 10.9级

Bolt, socket head

B229900000063

液压油过滤器

Filter, pilot AS

23000066

螺钉

Screw
