SY335C9I2KH hydraulic excavator SANY EGR






零件代码 PART NUMBER

名称 PART NAME

B222100000398

机油滤清器

Oil filter

A820205000942

接头

Fitting

B210780000028

直角组合接头

Fitting, Elbow

A210204000477

螺钉M10×110GB70.1 10.9级

Bolt

24000637

垫圈10GB97.1 达克锈

Washer

21008534

螺钉

Screw

12020025

管夹

Pipe Clamp

24000639

垫圈12GB97.1 达克锈

Washer

A210111000199

螺栓M12×20GB5783 10.9级

Bolt

60149606

线束固定夹

Clamp

12213205

放油管

Oil drain

11609465

接头

joint

B230101000356

O形圈

O-Ring-23.7

60148699

机油胶管

Rubber Hose

60148700

机油胶管

Rubber Hose

12931354

垫片

Gasket

A210855000003

喉箍

Clamp

12957641

燃油管

fuel return tube SY200B.1.3A.5-2C

13372661

燃油箱总成

Fuel Tank Assy.

12019940

软管

soft pipe








零件代码 PART NUMBER

名称 PART NAME

11348391

护孔环

Grommet

24000514

垫圈16GB93 达克锈

Washer

A210307000028

螺母

Nut

11251714

接头

Adapter

11331654

接头

Adapter

60046622

燃油开关

Switch, fuel

11273607

软管

Hose

12957788

燃油管

Oil-out tube of fuel tank

A229900001347

软管环箍

Clamp

A210204000358

螺钉M10×80GB70.1 10.9级

Bolt

60018743

柴油滤清器

Diesel Fuel Cleaner

A210204000355

螺钉M10×40GB70.1 10.9级

Bolt, socket head

A210459000002

垫圈

Washer

A210199000016

铰接螺栓

bolt

12786627

粗滤出油管

Oil-out tube of fuel tank

A210204000198

螺钉M16×35GB70.1 10.9级

Bolt, socket head

A210491000118

垫圈

High-strength steel washer

60006362

铜垫圈

Washer

11604207

放油阀接头

adapter

60006360

铜垫圈

Washer, copper








零件代码 PART NUMBER

名称 PART NAME

B220401000916

放油阀    Valve AS, drain

A229900001345

软管环箍    Clamp

A820606030088

粗滤水管    Coarse Water filter tube-








零件代码 PART NUMBER

名称 PART NAME

B229900004781

连接螺塞    Connecting screw plug

B222100000494

机油滤清器    Oil filter








零件代码 PART NUMBER

名称 PART NAME

60029642

液位传感器

Sensor GP, fuel level

13372660

燃油箱

Fuel Tank SY335C9I2K.1.3.5.4.1A

13733747

底盖总成

Pickup AS, fuel

A210405000006

垫圈

Washer

A210405000007

垫圈

Washer

B230101000934

形圈

O-ring

B230101000457

O形圈

O-ring

A210204000129

螺钉

Screw-M6×12GB70.1

A210111000090

螺栓

Bolt

60312034

燃油箱防盗锁盖

COVER OF FUEL TANK

60117826

燃油箱滤网

Strainer AS, fuel








零件代码 PART NUMBER

名称 PART NAME

60078250

Fuel Filter Seat

60201220

燃油粗滤芯

Fuel Strainer Element

60180565

集水杯

Water Cup

60078244

PLUG








零件代码 PART NUMBER

名称 PART NAME

60240318

推拉软轴

Sliding soft shaft

13134903

马达支架

motor

A210204000196

螺钉

Screw

A210491000120

垫圈

washer

13134718

防水罩

waterproof

11626828

油门电机拐臂

Throttle connecting lever

A210204000220

螺钉M8×20GB70.1 10.9级

Screw

24000633

垫圈8GB97.1 达克锈

Washer

A210111000012

螺栓 M10×20GB5783 10.9级

Bolt

10145126

停止器支架

Stopper support

A210111000092

螺栓

Bolt

B229900002662

电机Z带拉线

Stopper GP, electric

60099069

电机步进角1.8度

accelerograph motor

A210204000357

螺钉M10×60GB70.1 10.9级

Bolt

13161805

护套

Protective sleeve

60060565

垫圈8GB96.1 达克锈

Washer
