Part No. |
Description |
|
60099767 |
Assembly, clutch piston and seals |
|
60021234 |
Ring, piston |
|
60021238 |
Ring, seal, piston ring |
|
60021228 |
Blade, steel |
|
60099656 |
Plate, friction, outer, clutch |
|
60099652 |
Disc, pressure, friction plate, clutch |
|
60021237 |
Ring, clamp, pressure plate |
|
60099672 |
Seat, disc spring |
|
60099651 |
Spring, disc, return, clutch piston |
|
60099650 |
Seat, spring, clutch |
|
60099594 |
Ring, spacer, spring |
|
60099539 |
Bearing, 3rd gear |
|
60099540 |
Bearing, 3rd gear |
|
60099684 |
Ring, Snap |
|
60099685 |
Ring, spacer, bearing, 3rd gear |
|
60099772 |
Ring, seal, rubber, piston, 3rd gear shaft |
|
60121018 |
Bearing |
|
60099742 |
O-ring |
|
60099686 |
Cover, end, rear bearing, 3rd gear shaft |
|
60099676 |
Ring, spacer, rear bearing, forward gear shaft |
|
60121053 |
O-ring |
|
60099780 |
Plug, hole, checking |
|
Part No. |
Description |
|
60099750 |
O-ring |
|
60099735 |
Stud, end cap, bearing |
|
60099739 |
Lock washer, stud, bearing end cap |
|
60099738 |
Nut, stud, bearing end cap |
|
Part No. |
Description |
|
60099557 |
Gear, 3rd gear |
|
60099558 |
Gear, driving, 3rd gear |
|
Part No. |
Description |
|
60099762 |
Assembly, 2nd gear clutch piston and seals |
|
60099763 |
Ring, seal, outer, 3nd gear clutch piston |
|
60021238 |
Ring, seal, piston ring |
|
60099771 |
Assembly, forward gear clutch piston and seals |
|
60099768 |
Ring, seal, outer, clutch piston |
|
60021238 |
Ring, seal, piston ring |
|
60099654 |
Plate, friction, inner, clutch |
|
60099655 |
Plate, friction, outer, clutch |
|
60099653 |
Disc, pressure, friction plate, clutch |
|
60099712 |
Ring, clamp, pressure disc |
|
60099714 |
Ball, stop, pressure plate |
|
60099713 |
Spring, stop, pressure plate |
|
60099615 |
Assembly, disc spring |
|
60099595 |
Retainer, Snap Ring |
|
60099596 |
Ring, Snap |
|
60099651 |
Spring, disc, return, clutch piston |
|
60099671 |
Retainer, Spring |
|
60099670 |
Retainer, Spring |
|
60099596 |
Ring, Snap |
|
60099536 |
Bearing, driving gear, clutch |
|
60099535 |
Bearing, driving gear, clutch |
|
60099766 |
Seal, oil, clutch hub |
|
Part No. |
Description |
|
60099657 |
Ring, Locating, Driving Gear, Clutch |
|
60099534 |
Bearing, front, backward gear and 2nd gear shaft |
|
60099678 |
Ring, Snap |
|
60099677 |
Ring, locating, front bearing |
|
60099565 |
Hub, 2nd clutch |
|
60099621 |
Ring, snap, locating, 2nd gear clutch hub |
|
60099620 |
Seat, locating ring, 2nd gear clutch hub |
|
60099619 |
Ring, locating, 2nd gear clutch hub |
|
60099769 |
Seal, Piston |
|
60099654 |
Plate, friction, inner, clutch |
|
60099655 |
Plate, friction, outer, clutch |
|
60099622 |
Disc, pressure, friction plate, 2nd gear clutch |
|
Part No. |
Description |
|
60099548 |
Bearing, guide, 1st gear clutch shaft |
|
60099719 |
Ring, snap, front bearing, first gear clutch shaft |
|
60099718 |
Ring, spacer, front bearing, first gear clutch shaft |
|
60099551 |
Ring, outer, front cone-shape bearing, first gear clutch shaft |
|
60021238 |
Ring, seal, piston ring |
|
60099763 |
Ring, seal, outer, 3nd gear clutch piston |
|
60099775 |
Assembly, first gear clutch piston and seal ring |
|
60099654 |
Plate, friction, inner, clutch |
|
60099655 |
Plate, friction, outer, clutch |
|
60099622 |
Disc, pressure, friction plate, 2nd gear clutch |
|
60099712 |
Ring, clamp, pressure disc |
|
60099672 |
Seat, disc spring |
|
60099651 |
Spring, disc, return, clutch piston |
|
60099594 |
Ring, spacer, spring |
|
60099715 |
Ring, spacer, 1st gear |
|
60099539 |
Bearing, 3rd gear |
|
60099684 |
Ring, Snap |
|
60099540 |
Bearing, 3rd gear |
|
60099750 |
O-ring |
|
60099716 |
Washer, thrust, first gear bearing |
|
60099549 |
Assembly, rear bearing, first gear clutch shaft |
|
60099737 |
Stud, end cap, bearing |
|
Part No. |
Description |
|
60099776 |
O-ring, bearing end cap |
|
60099731 |
Gasket, thin, end cap, bearing |
|
60099700 |
Washer, Lock |
|
60099640 |
Nut |
|
60099780 |
Plug, hole, checking |
|
60099721 |
Cover, end, rear bearing, first gear shaft |
|
60099769 |
Seal, Piston |
|
60099550 |
Bearing, front, cone-shape, first gear clutch shaft |
|
60099650 |
Seat, spring, clutch |
|
Part No. |
Description |
|
60099762 |
Assembly, 2nd gear clutch piston and seals |
|
60099763 |
Ring, seal, outer, 3nd gear clutch piston |
|
60021238 |
Ring, seal, piston ring |
|
60099654 |
Plate, friction, inner, clutch |
|
60099655 |
Plate, friction, outer, clutch |
|
60099622 |
Disc, pressure, friction plate, 2nd gear clutch |
|
60099712 |
Ring, clamp, pressure disc |
|
60099670 |
Retainer, Spring |
|
60099651 |
Spring, disc, return, clutch piston |
|
60099596 |
Ring, Snap |
|
60099671 |
Retainer, Spring |
|
60099544 |
Bearing, front, gear 4 |
|
60099694 |
Ring, Snap |
|
60099693 |
Ring, locating, front bearing, gear 4 |
|
60099567 |
Hub, 4th gear clutch |
|
60099691 |
Ring, locating, hub, gear 4 clutch |
|
60099769 |
Seal, Piston |
