13556945 |
左门总成 |
Left Door Assy |
|
13328858 |
继电器安装板 |
Bracket, mount, start relay |
|
11673094 |
启动继电器护罩 |
Starter Relay protective cover |
|
A210111000202 |
螺栓 |
Bolt |
|
13603369 |
副水箱安装支架 |
Bracket, mount, door AS |
|
12786106 |
蓄电池盖板 |
Battery cover |
|
A210307000036 |
螺母 |
Nut |
|
60060546 |
垫圈10GB96.1 达克锈 |
Washer |
|
12738866 |
蓄电池支架 |
Hold down, battery |
|
11592968 |
双头螺柱 |
Stud, battery hold down |
|
12569035 |
蓄电池胶垫 |
Rubber pad, battery |
|
A820606030643 |
蓄电池胶垫 |
Rubber pad, battery |
|
A820699000269 |
底海绵 |
Foam, bottom |
|
13556731 |
空滤下隔板 |
Partition |
|
13556732 |
下隔板密封海绵 |
Foam, lower |
|
13465997 |
上隔板密封海绵 |
Foam, upper |
|
13465996 |
空滤上隔板 |
Partition |
|
13557058 |
柴油机左隔板 |
Partition, engine |
|
14052212 |
柴油机右隔板 |
Right clapboard of diesel engine |
|
13556750 |
顶封板 |
Partition, engine |
|
13556761 |
Partition, engine |
|
13556763 |
Partition, pump |
|
13957495 |
Partition, pump |
|
12698255 |
Right Door Assy. |
|
13557183 |
Bracket, frame support |
|
13556735 |
Frame, support |
|
A810502015065 |
Rod, hood support |
|
A210508000009 |
Pin |
|
A210491000014 |
Pin, cotter |
|
A820302010101 |
Support, hood |
|
13557056 |
Beam |
|
60262513 |
Washer |
|
13556759 |
Beam |
|
13556752 |
Beam |
|
13556730 |
Foam, rear beam |
|
60228208 |
后视镜 rearview mirror |
|
12046539 |
右下后视镜支架组件 Bracket, mirror |
|
11475138 |
扶手主体 Handrail AS |
|
11817247 |
Fixed Clamp |
|
60196657 |
door lock |
|
11817218 |
check nut |
|
60238783 |
Washer |
|
11938430 |
Lever |
|
A210491000007 |
Pin, Cotter |
|
11413341 |
Sealing strip |
|
12908470 |
Tool Box Main Body |
|
零件代码 PART NUMBER |
|
|
13625854 |
Engine hood, right |
|
11961759 |
Cramp |
|
13581649 |
Foam |
|
A210307000036 |
Nut |
|
A810502019056 |
Setscrew |
|
A210111000343 |
Bolt |
|
60060565 |
Washer |
|
13647185 |
Cover |
|
13625860 |
Radiator hood |
|
13556962 |
Seal |
|
11342744 |
Foam |
|
零件代码 PART NUMBER |
|
|
14251016 |
small door |
|
14250873 |
right door |
|
A810502019056 |
Setscrew |
|
12669836 |
washer |
|
12669837 |
washer |
|
12669838 |
door-shaft seal |
|
A210405000001 |
Washer |
|
A210111000038 |
Bolt |
|
12196084 |
Rod, door |
|
13556951 |
Frame, left doors |
|
A210307000001 |
Nut |
|
12898634 |
Rod, door |
|
零件代码 PART NUMBER |
|
|
13556952 |
door plate |
|
A210111000343 |
Bolt |
|
24000633 |
Washer |
|
13996527 |
Groove plate |
|
零件代码 PART NUMBER |
|
|
11817247 |
Fixed Clamp |
|
12677406 |
door plateSY365C8I2KS.1.6.24.2- |
|
13996527 |
Groove plate |
|
24000633 |
Washer |
|
A210111000343 |
Bolt |
|
12735024 |
Gasket, rubber |
|
11817218 |
check nut |
|
11817247 |
Fixed Clamp |
|
14250873 |
right door |
|
12698260 |
right door frame |
|
A210405000001 |
Washer |
|
A210307000001 |
Nut |
|
12196084 |
Rod, door |
|
A810502019056 |
Setscrew |
|
A210111000038 |
Bolt |
|
12669838 |
door-shaft seal |
|
12669837 |
washer |
|
12669836 |
washer |
