10713051 Air conditioning system Q400C.27(b

10713051 Air conditioning system Q400C.27(b

1 A210111000081 bolt M6×25GB5783 4
2 A210401000016 Washer 6GB93 8
3 A210405000006 Washer 6GB97.1 4
4 10712870 Air conditioning assembly Q400C.27(b).1 1
5 A210111000197 bolt M10×25GB5783 10.9 level 4
6 A210401000001 Washer 10GB93 18
7 A210405000011 gasket 10GB97.1 18
8 A210210000008 screw M6×16GB818 4
9 A210204000009 screw M10×45GB70.1 6
10 A210307000017 Nut M10GB6170 6
11 10712583 Thin nut Q280.27(a)-1 1
12 A210401000002 gasket 12GB93 1
13 21015813 key GB1099 1
14 10701844 Air conditioning hydraulic system 1
15 10709847 bracket welding 1
16 A210204000010 screw M10×50GB70.1 4
17 A210111000026 bolt M10×35GB5783 10.9 level 4

10712870 空调总成Q400C.27(b).1

1 10693715 External air circulation joint Q50E.27(c).1.2 0
2 A229900007800Air Duct0
3 60005680 Evaporator Q/SY015018 0
4 A229900009099 water diversion hose 0
5 21053361 hose hoop φ22-φ32QC619 0
6 A229900009098 Air Duct 0
7 21004577 Hose hoop φ42-φ65QC619 0
8 A229900009096 Air Duct 0
9 60015895 Storage-steam pipe assembly SY2060700003 0
10 60015912 Steam-pressure pipe assembly SY2060700004 0
11 A229900009470 Hot water hose 0
12 10709828 Air conditioner outdoor unit assembly 0
13 10712587 conversion connector Q400C.27(b).1-2 0
14 10712586 Conversion connector Q400C.27(b).1-1 0
15 60014615 Controller assembly SY2000800010 0
16 60014609 Air conditioning wire harness SY2000800028 400t 0
17 A229900009466 Air Duct 0
