SY335C9I2KH hydraulic excavator SANY ABR



零件代码 PART NUMBER

名称 PART NAME

60347014

电机总成

Generator assembly

60144880

螺母

Nut M10GB6177.1

60347015

防水罩

Waterproof cover

60347016

六角螺母

Hex nut

60347017

平垫圈

Flat washer

60347018

橡胶平垫圈

Rubber flat washer

60347019

全卡

Clip

60347020

平垫圈

Flat washer

60347021

输出轴

Shaft output

60347022

输出轴套组件

Shaft sleeve groupware

60347023

摇臂中心距

Rocker arm

60347024

摇臂球头

Rocker arm ball head

60347025

橡皮碗

Leather cup

60347026

平垫圈

Flat washer

60347027

全卡

Clip

60347028

支架组件

Support component

60144906

螺栓M6×16GB16674.1 镀黑锌

Bolt

A210111000081

螺栓

Bolt

A210401000016

垫圈

Washer

60347029

曲柄中心距

Crank








零件代码 PART NUMBER

名称 PART NAME

60347030

防松螺母

Lock nut

60347031

曲柄球头

Crank ball head

60347032

连杆组件

Connecting rod components

60347033

平垫圈

Flat washer

60347034

全卡

Clip










零件代码 PART NUMBER

名称 PART NAME

60043585

吊环螺钉

Lifting ring screw

A229900009417

前窗把手

Handle,window,front

61018437

减震器孔堵头

Plug,rubber

61019358

前下玻璃内胶条

Block gine,window,lower,front

A230105000108

前风窗整体密封胶条

Windscreen Integral Seal Rubber

60083342

上车外拉手

Handle

14048784

后视镜支架

bracket for rear view mirror

60228208

后视镜

rearview mirror

60043862

驾驶室内拉手

Inner handrail of Cab.

61019359

反扣锁压杆限位板

Plate,lock

60046374

锁扣

Lock catch

61019360

反扣锁弹簧

Spring,lock

A229900004764

驾驶门锁内把手

Driver-Side DoorLock Inner

A222200000094

门反扣锁总成

Lock AS

A229900009412

驾驶室门铰链

Hinge,door,cab

61019361

门限位块

Block,door

61019362

前移窗后限位块

Block,rear,forward window

A229900003883

平衡器

A229900003883

A230105000110

后风窗玻璃胶条

Rear Windscreen Glass Rubber










零件代码 PART NUMBER

名称 PART NAME

A230105000113

顶天窗密封胶条

Sunroof Seal Rubber Strip

61019363

左拐角

Corner,left

61019364

显示屏支架

Bracket

61019365

显示屏支架安装架

Frame

13874081

扬子驾驶室前下护网

Yangzi cab protective net

61019366

门框胶条

Seal,Door-frame

61019367

门框胶条压盖

Housing, seal

A230105000111

驾驶门框整体密封胶皮

Driver-Side Door Frame Integral

61019368

门槛条

Strip

61019369

外气过滤器压板

Plate

61019357

侧风道压板

Plate,air duct

61019370

后部海绵

Foam, rear

61019371

衣帽钩

Hook








零件代码 PART NUMBER

名称 PART NAME

61019372

空调盖板左安装板

Plate, left

61019373

空调盖板右安装板

Plate, right

61019374

空调盖板

Cover,air conditioner

61019375

后锁扣

Latch,rear

61019376

前窗限位块中部

Block,middle,front window

61019377

前窗锁柱

Lock cylinder,front window

A229900004767

顶天窗锁止块

Sunroof Locking Block

61019378

前移窗缓冲块

Buffer block

A229900004683

刮水刷托架

Bracket,wiper

61019379

前窗下限位

Limit block,lower

61019380

前下玻璃限位块

Limit block

61019381

丝座堵头

Plug

61019382

前下玻璃缓冲块

Buffer block,glass,lower,front

61019383

风门缓冲块

Buffer block










零件代码 PART NUMBER

名称 PART NAME

A230300000107

右侧固定玻璃

Glass, right

A230300000100

前围上移玻璃

Glass, upper

A230300000101

前围下固定窗玻璃

Front Side Lower Fixed Window

A230300000102

驾驶窗前玻璃

Glass, cab front

A230300000104

左侧下固定玻璃

Glass, lower left

A230300000103

驾驶窗后玻璃

Glass, rear

A230300000105

左侧后固定玻璃

Left Side Rear Fixed Glass

A230300000106

后风窗玻璃

Glass, rear

A230300000108

顶天窗玻璃

Glass, roof










零件代码 PART NUMBER

名称 PART NAME

61019392

风门板

Plate,throttle

61019393

风门锁

Lock,throttle

60060564

垫圈6GB93 达克锈

Washer

A210111000079

螺栓

Bolt

A210307000016

螺母

Nut

24000632

垫圈6GB97.1 达克锈

washer

61019394

风门挡板

Plate, retaining,throttle










零件代码 PART NUMBER

名称 PART NAME

60085462

驾驶室门窗

Glass

A230105000112

驾驶门上密封皮

Driver-Side Door Upper Seal

61019384

锁环后盖

Cover, rear

61019385

门板

Plate

60036511

驾驶室门锁塑料护板

Protective board of door lock

A229900003762

门锁总成

Door Lock Assy. EMC0512.6

A230300000104

左侧下固定玻璃

Glass, lower left

A229900004681

门反扣碰销

Door Anti-Locking Pin

61019386

锁环护套

Grommet

A210307000036

螺母

Nut

24000637

垫圈10GB97.1 达克锈

Washer

A229900004764

驾驶门锁内把手

Driver-Side DoorLock Inner
