SY335C9I2KH hydraulic excavator SANY DBR

60008593

护罩

Cover, rubber

60038339

定位螺栓

Bolt, positioning

60008591

凸轮

Plate, cam

60008592

调整螺杆

Screw, adjusting

60038480

螺母

Nut

60038527

螺栓

Bolt

60008791

Cover

60038181

衬套

Sleeve

60008585

凸轮轴

Camshaft








零件代码 PART NUMBER

名称 PART NAME

60008754

Cover

60008776

防尘圈

Ring, dust

60008780

Plug

60038720

O形圈

O-ring

60008813

推杆

Plunger

60008803

活塞

Piston

60008767

弹簧

Spring

60008766

弹簧

Spring

60008756

弹簧座

Seat, spring

60038140

轴承钢珠

Bearing, ball

60038563

内六角螺钉

Bolt

60038605

外壳(阻尼器)

Casing, damper










零件代码 PART NUMBER

名称 PART NAME

60038820

O形圈

O-ring

60008596

垫圈

Washer

60008757

弹簧座

Seat, spring

60038221

弹簧

Spring

60008594

弹簧

Spring

60008589

垫圈

Washer

60008597

垫圈

Washer

60008588

柱塞

Plunger

60038727

O形圈

O-ring

60008728

紧定螺钉

Setscrew

60038436

壳体

Housing

60038702

Seat

60038020

Collar

60038139

轴承钢珠

Bearing, ball

60038703

Seat

60038487

螺塞

Plug, screw










零件代码 PART NUMBER

名称 PART NAME

60008879

弹簧销

Pin, roll

60008604

调整螺母

Nut, adjusting

60008809

圆板

Plate, circular

60008602

接头

Connector

60008603

密封圈

Ring, seal

60008595

堵头

Plug

B230101000363

O形圈

O-ring

60008599

推动杆

Pushrod

60008811

Plate

60008758

弹簧座

Seat, spring

60008775

弹簧

Spring

60008597

垫圈

Washer

60008774

弹簧

Spring

60008760

滑轴

Spool

60008795

壳体

Housing

60008799

O形圈

O-ring

60008810

油口接板

Plate, connecting, oil port

60008786

内六角螺钉

Screw, socket head

60008598

密封垫圈

Washer, seal

60008806

衬套

Sleeve








零件代码 PART NUMBER

名称 PART NAME

A820205000836

接头

Connector

A229900001581

O形圈

O-ring

A820205000839

接头

Connector

A230101000247

O形圈

O-ring

60000307

胶管

Rubber hose

21030631

胶管

Hose, rubber

A820205000945

G1-M30接头

Connector

B230101000050

O形圈

O-ring

A820205000962

接头

Connector

B230101000090

O形圈

O-ring

B230103000975

胶管

Hose, rubber

A820205000940

接头

Connector

B230101000047

O形圈

O-ring

B230103001258

胶管

Hydraulic Hose Assembly

B230103001022

胶管

Hose

B210780000024

管接头

Connector, pipe

A820205000961

G3/8-M18接头

Connector

B230101000049

O形圈

O-ring

A820205000947

堵头

Plug

B210780000028

管接头

Connector, pipe










零件代码 PART NUMBER

名称 PART NAME

A820205001771

堵头

Plug

B230103002712

胶管

Hose

60136331

六联电磁换向阀组

Valve GP, solenoid, directional

A210204000345

螺钉M10×70GB70.1 10.9级

Screw M10×70GB70.1 10.9 grade

24000637

垫圈10GB97.1 达克锈

Washer

12395992

G3/8-M18过滤接头

Connector, filter

60137145

蓄能器

Accumulator

B210780000170

管接头

Connector, pipe

B210780000827

管接头

Connector, pipe

B210780000016

管接头

Connector, pipe

B210780001310

管接头

Connector, pipe

B210780001007

管接头

Connector, pipe

A820205000838

接头

Connector

A230101000243

O形圈

O-ring

10077549

接头

Connector, internal

A820205001144

M33-M30接头

Connector

B230101000036

O形圈

O-ring

B210780000018

管接头

Connector, pipe










零件代码 PART NUMBER

名称 PART NAME

60065224

电磁切换阀    Valve, solenoid, changeover

60065222

电磁比例减压阀    Valve, solenoid, proportional










零件代码 PART NUMBER

名称 PART NAME

B230103000914

胶管

Hose

B230103001456

胶管

Hose

B230103000808

胶管

Hose, rubber

A210110000437

螺栓M12×65GB5782 10.9级

Bolt

24000513

垫圈12GB93 达克锈

Washer 12GB93

B230103000993

胶管

Hose, rubber

A831213050000

胶管

Hose, rubber

B230103000977

胶管

Hose, rubber

B230103002045

胶管

Hose

10237402

继电器防护板

Plate, guard, relay

10077269

过渡块

Adapter

B210780000172

管接头

Connector, pipe

11415538

过渡块板

Plate, adapter

B230103004133

胶管

Hose

B210780000170

管接头

Connector, pipe

60020078

过滤接头

Connector, filter

B230103001947

胶管

Hose
