零件代码 PART NUMBER |
名称 PART NAME |
|
|
60038622 |
斜盘 |
Plate, swash |
|
60062348 |
配油盘 |
Tray, oil distribution |
|
60038393 |
活塞 |
Piston |
|
60038224 |
弹簧 |
Spring |
|
60038037 |
制动片 |
Brake shoe |
|
60038017 |
配合板 |
Plate, fitting |
|
60038867 |
油封 |
Seal, oil |
|
零件代码 PART NUMBER |
名称 PART NAME |
|
|
60038470 |
螺钉 |
Bolt |
|
60038581 |
平销 |
Pin |
|
60038291 |
挡圈 |
Ring, retaining |
|
60037975 |
隔片 |
Spacer |
|
60038044 |
钢球 |
Ball, steel |
|
60039305 |
驱动齿轮 |
Gear, drive |
|
60039306 |
输入齿轮 |
Gear, input |
|
60038346 |
法兰 |
Flange |
|
60037976 |
隔片 |
Spacer |
|
60038875 |
联接器 |
Coupler |
|
A210416000025 |
挡圈 |
Ring, retainer 95GB893.1 |
|
A210416000041 |
挡圈 |
Retainer Ring 40GB893.1 |
|
60038806 |
O形圈 |
O-ring |
|
60038801 |
O形圈 |
O-ring |
|
24002206 |
螺钉 |
Bolt |
|
零件代码 PART NUMBER |
名称 PART NAME |
|
12265744 |
挖掘机操作保养手册(英) Manual, operation and |
|
11826337 |
三一挖掘机保养及保修手册（英） Manual, operation and |
|
12535566 |
三一液压挖掘机操作与保养光碟（ CD, excavator maintenance |
|
12753754 |
配重主体 Main counterweight |
|
10789112 |
履带总成 Track GP |
|
11920028 |
履带架 Frame, track |
|
A210110000307 |
螺栓 Bolt |
|
A210111000221 |
螺栓M20×50GB5783 10.9级 Bolt M20×50GB5783 10.9 |
|
A210491000132 |
垫圈 Washer 20GB1230 |
|
A210491000144 |
垫圈 Washer 18(GB1230) |
|
A810401990037 |
护板 Board, guard |
|
B230101000047 |
O形圈 O-ring |
|
B230103003016 |
胶管 Hose |
|
B230101000456 |
O形圈 O-ring |
|
B230101000996 |
O形圈 O-ring |
|
B230103005242 |
胶管 Hose |
|
A820101216696 |
三管管卡 Clamp, 3-pipe |
|
12631571 |
硬管 Pipe, hard |
|
B230103005422 |
胶管 Rubber hose 4SH25-SFL-SFL45- |
|
11144317 |
管夹 Clamp |
|
零件代码 PART NUMBER |
名称 PART NAME |
|
13068570 |
加长臂动臂灯线束 Work Lamp |
