零件代码 PART NUMBER |
名称 PART NAME |
|
|
21005186 |
螺栓 |
Bolt M10×40GB5783 10.9 |
|
11243374 |
压板 |
Plate, pressure |
|
11243400 |
压板 |
Plate, pressure |
|
B230103003282 |
胶管 |
Hose, rubber |
|
B230103003202 |
胶管 |
Hose |
|
A820601990304 |
法兰 |
Flange |
|
A820601990336 |
波纹管 |
Bellows |
|
A210111000079 |
螺栓 |
Bolt M6×16GB5783 |
|
A210401000016 |
垫圈 |
Washer 6GB93 |
|
B210780000418 |
管接头 |
Connector, pipe |
|
B210780000024 |
直角组合接头 |
Elbow |
|
A820205000894 |
接头 |
Connector |
|
A230101000247 |
O形圈 |
O-ring 10.9×2.3(JISB2401) |
|
A820205000839 |
接头 |
Connector |
|
A820205000940 |
接头 |
Connector |
|
B230101000047 |
O形圈 |
O-ring |
|
A820205000946 |
接头 |
Connector |
|
B230101000049 |
O形圈 |
O-ring 13.8×2.4JISB2401 |
|
B229900001613 |
左手柄 |
Joystick, left |
|
A241200000875 |
钮开关 |
Switch |
|
零件代码 PART NUMBER |
名称 PART NAME |
|
|
A210405000011 |
垫圈 |
Washer 10GB97.1 |
|
A210264000022 |
自攻螺钉 |
Screw, self-tapping |
|
11050165 |
手柄 |
Handle, grip |
|
A210308000006 |
螺母 |
Nut M12×1.25GB6171 |
|
A210307000025 |
螺母 |
Nut M14GB6170 |
|
A229900006446 |
罩 |
Hood |
|
A229900001028 |
罩 |
Hood |
|
A229900001027 |
板 |
Plate |
|
B229900001614 |
右手柄 |
Joystick, right |
|
60020078 |
过滤接头 |
Connector, filter |
|
11243401 |
胶套 |
Sleeve, rubber |
|
11602359 |
橡胶垫 |
Gasket, rubber |
|
60128281 |
胶管 |
Hose |
|
60086354 |
线束固定夹 |
Clamp, harness |
|
11742013 |
喇叭开关线束 |
Harness, horn switch |
|
60116344 |
插入件 |
Insertion piece |
|
零件代码 PART NUMBER |
名称 PART NAME |
|
|
60008879 |
弹簧销 |
Pin, roll |
|
60008604 |
调整螺母 |
Nut, adjusting |
|
60008809 |
圆板 |
Plate, circular |
|
60008602 |
接头 |
Connector |
|
60008603 |
密封圈 |
Ring, seal |
|
60008595 |
堵头 |
Plug |
|
B230101000363 |
O形圈 |
O-ring |
|
60008599 |
推动杆 |
Pushrod |
|
60008811 |
板 |
Plate |
|
60008758 |
弹簧座 |
Seat, spring |
|
60008775 |
弹簧 |
Spring |
|
60008597 |
垫圈 |
Washer |
|
60008774 |
弹簧 |
Spring |
|
60008760 |
滑轴 |
Spool |
|
60008795 |
壳体 |
Housing |
|
60008799 |
O形圈 |
O-ring |
|
60008810 |
油口接板 |
Plate, connecting, oil port |
|
60008786 |
内六角螺钉 |
Screw, socket head |
|
60008598 |
密封垫圈 |
Washer, seal |
|
60008806 |
衬套 |
Sleeve |
|
零件代码 PART NUMBER |
名称 PART NAME |
|
|
60008593 |
护罩 |
Cover, rubber |
|
60038339 |
定位螺栓 |
Bolt, positioning |
|
60008591 |
凸轮 |
Plate, cam |
|
60008592 |
调整螺杆 |
Screw, adjusting |
|
60038480 |
螺母 |
Nut |
|
60038527 |
螺栓 |
Bolt |
|
60008791 |
盖 |
Cover |
|
60038181 |
衬套 |
Sleeve |
|
60008585 |
凸轮轴 |
Camshaft |
|
零件代码 PART NUMBER |
名称 PART NAME |
|
|
60008754 |
盖 |
Cover |
|
60008776 |
防尘圈 |
Ring, dust |
|
60008780 |
堵 |
Plug |
|
60038720 |
O形圈 |
O-ring |
|
60008813 |
推杆 |
Plunger |
|
60008803 |
活塞 |
Piston |
|
60008767 |
弹簧 |
Spring |
|
60008766 |
弹簧 |
Spring |
|
60008756 |
弹簧座 |
Seat, spring |
|
60038140 |
轴承钢珠 |
Bearing, ball |
|
60038563 |
内六角螺钉 |
Bolt |
|
60038605 |
外壳(阻尼器) |
Casing, damper |
|
零件代码 PART NUMBER |
名称 PART NAME |
|
|
60038820 |
O形圈 |
O-ring |
|
60008596 |
垫圈 |
Washer |
|
60008757 |
弹簧座 |
Seat, spring |
|
60038221 |
弹簧 |
Spring |
|
60008594 |
弹簧 |
Spring |
|
60008589 |
垫圈 |
Washer |
|
60008597 |
垫圈 |
Washer |
|
60008588 |
柱塞 |
Plunger |
|
60038727 |
O形圈 |
O-ring |
|
60008728 |
紧定螺钉 |
Setscrew |
|
60038436 |
壳体 |
Housing |
|
60038702 |
座 |
Seat |
|
60038020 |
套 |
Collar |
|
60038139 |
轴承钢珠 |
Bearing, ball |
|
60038703 |
座 |
Seat |
|
60038487 |
螺塞 |
Plug, screw |
|
零件代码 PART NUMBER |
名称 PART NAME |
|
|
A820205000940 |
接头 |
Connector |
|
变更或见其他配置 |
O形圈 |
O-ring |
|
A820205002280 |
接头 |
Connector |
|
B230101000090 |
O形圈 |
O-ring 17.8×2.4JISB2401 |
|
60184562 |
胶管 |
Hose |
|
21030908 |
胶管 |
Hose Assembly |
|
B230103000300 |
胶管 |
Hose, rubber |
|
A820205000945 |
管接头 |
Connector |
|
B230101000050 |
O形圈 |
O-ring 28.7×3.5JISB2401 |
|
B210780000170 |
管接头 |
Connector, pipe |
|
A831213050000 |
胶管 |
Hose, rubber |
|
B230101000049 |
O形圈 |
O-ring 13.8×2.4JISB2401 |
|
12395992 |
G3/8-M18过滤接头 |
Connector, filter |
|
B210780000024 |
直角组合接头 |
Elbow |
|
B210780000016 |
三通组合L型接头 |
Tee |
|
B210780000827 |
管接头 |
Connector, pipe |
|
23000905 |
胶管 |
Hose, rubber |
|
B210780000418 |
管接头 |
Connector, pipe |
|
A820205001771 |
堵头 |
Plug |
|
A820205000961 |
管接头 |
Connector |
|
零件代码 PART NUMBER |
名称 PART NAME |
|
|
60137145 |
隔膜式蓄能器 |
Accumulator |
|
B230103003212 |
胶管 |
Hose, rubber |
|
B230103000863 |
胶管 |
Hose, rubber |
|
60136331 |
六联电磁换向阀组 |
Valve GP, solenoid, directional |
|
A210204000358 |
螺钉M10×80GB70.1 10.9级 |
Screw M10×80GB70.1 10.9 |
|
A210401000001 |
垫圈 |
Washer 10GB93 |
|
A820205000947 |
堵头 |
Plug |
|
B210780000018 |
管接头 |
Connector, pipe |
