Body,container reach stacker, SRSC45H1 SFR SVE





Item No.

Part No.

Description

Qty.

1

60099771

Assembly, forward gear clutch piston and seals

1

2

60099768

Ring, seal, outer, clutch piston

1

3

60021238

Ring, seal, piston ring

1

4

60099654

Disc, Friction, Inner, Clutch

12

5

60099655

Disc, Friction, Outer, Clutch

11

6

60099653

Disc, pressure, friction plate, clutch

1

7

60099714

Ball, stop, pressure plate

1

8

60099713

Spring, stop, pressure plate

1

9

60099712

Ring, Snap

1

10

60099766

Seal, Clutch Hub

1

11

60099595

Seat, snap ring

1

12

60099536

Bearing, Driving Gear, Clutch

1

13

60099535

Bearing, Driving Gear, Clutch

1

14

60099657

Ring, Locating, Driving Gear, Clutch

1

15

60099596

Ring, Snap

1

16

60099615

Assembly, disc spring

1

17

60099537

Bearing, Front, Forward Gear Shaft

1

18

60099677

Ring, Locating, Front Bearing

2

19

60099769

Seal, Piston

2

20

60121018

Bearing

1

21

60099642

Spring, clamp, rear bearing

1

22

60099676

Ring, Spacer, Rear Bearing

1


















Item No.

Part No.

Description

Qty.

1

60099767

Assembly, clutch piston and seals

1

2

60021234

Ring, piston

1

3

60021238

Ring, seal, piston ring

1

4

60021228

Blade, steel

12

5

60099656

Plate, friction, outer, clutch

12

6

60099652

Disc, pressure, friction plate, clutch

1

7

60021237

Ring, clamp, pressure plate

1

8

60099672

Retainer, Spring

1

9

60099651

Spring, Return

1

10

60099650

Seat, Spring, Clutch

1

11

60099594

Spacer Ring

1

12

60099539

Bearing, 3rd gear

1

13

60099540

Bearing, 3rd Gear

1

14

60099684

Ring, Snap

2

15

60099685

Ring, spacer, bearing, 3rd gear

1

16

60099772

Ring, seal, rubber, piston, 3rd gear shaft

1

17

60121018

Bearing

1

18

60099742

O-ring

1

19

60099686

Cover, end, rear bearing, 3rd gear shaft

1

20

60099676

Ring, Spacer, Rear Bearing

1

21

60121053

O-ring

1

22

60099780

Plug

1


















Item No.

Part No.

Description

Qty.

23

60099750

O-ring

1

24

60099735

Stud

4

25

60099739

Washer, Lock

4

26

60099738

Nut

4
























Item No.

Part No.

Description

Qty.

1

60099557

Gear, 3rd gear

1

2

60099558

Gear, driving, 3rd gear

1
















Item No.

Part No.

Description

Qty.

1

60099762

2nd Gear Clutch Piston and Seals

1

2

60099763

Seal

1

3

60021238

Ring, seal, piston ring

1

4

60099771

Assembly, forward gear clutch piston and seals

1

5

60099768

Ring, seal, outer, clutch piston

1

6

60021238

Ring, seal, piston ring

1

7

60099654

Disc, Friction, Inner, Clutch

12

8

60099655

Disc, Friction, Outer, Clutch

11

9

60099653

Disc, pressure, friction plate, clutch

1

10

60099712

Ring, Snap

2

11

60099714

Ball, stop, pressure plate

1

12

60099713

Spring, stop, pressure plate

1

13

60099615

Assembly, disc spring

1

14

60099595

Seat, snap ring

1

15

60099596

Ring, Snap

1

17

60099651

Spring, Return

1

18

60099671

Retainer, Spring

1

19

60099670

Retainer, Spring

1

20

60099596

Ring, Snap

1

21

60099536

Bearing, Driving Gear, Clutch

1

22

60099535

Bearing, Driving Gear, Clutch

1

23

60099766

Seal, Clutch Hub

1
















Item No.

Part No.

Description

Qty.

24

60099657

Ring, Locating, Driving Gear, Clutch

1

25

60099534

Bearing, front, backward gear and 2nd gear shaft

1

26

60099678

Ring, Snap

1

27

60099677

Ring, Locating, Front Bearing

2

28

60099565

Hub, 2nd Clutch

1

29

60099621

Ring, Snap

1

30

60099620

Seat, Locating Ring, 2nd Gear Clutch Hub

1

31

60099619

Ring, Locating, 2nd Gear Clutch Hub

1

32

60099769

Seal, Piston

3

33

60099654

Disc, Friction, Inner, Clutch

12

34

60099655

Disc, Friction, Outer, Clutch

11

35

60099622

Disc, Pressure, Friction Plate, 2nd Gear Clutch

1
















Item No.

Part No.

Description

Qty.

1

60099548

Bearing

1

2

60099719

Ring, Snap

1

3

60099718

Ring, Spacer

1

4

60099551

Ring, Retainer

1

5

60021238

Ring, seal, piston ring

1

6

60099763

Seal

1

7

60099775

Piston and Seal Assembly

1

8

60099654

Disc, Friction, Inner, Clutch

10

9

60099655

Disc, Friction, Outer, Clutch

10

10

60099622

Disc, Pressure, Friction Plate, 2nd Gear Clutch

1

11

60099712

Ring, Snap

1

13

60099672

Retainer, Spring

1

14

60099651

Spring, Return

1

15

60099594

Spacer Ring

1

16

60099715

Ring, Spacer, 1st Gear

1

17

60099539

Bearing, 3rd gear

1

18

60099684

Ring, Snap

1

19

60099540

Bearing, 3rd Gear

1

20

60099750

O-ring

2

21

60099716

Washer, Thrust

1

22

60099549

Bearing

1

23

60099737

Stud

4
















Item No.

Part No.

Description

Qty.

24

60099776

O-ring

1

25

60099731

Gasket, Thin

1

26

60099700

Washer, Lock

4

27

60099640

Nut

4

28

60099780

Plug

2

29

60099721

Cap

1

30

60099769

Seal, Piston

2

31

60099550

Bearing

1

32

60099650

Seat, Spring, Clutch

1
