Body,container reach stacker, SRSC45H1 CUM
















Item No.

Part No.

Description

Qty.

23

A241000000291

Pin

207

24

11619369

Pad, rubber

1

25

12561952

Busbar, copper, grounding, empty container handler

1

26

60162155

Terminal, copper wire, peephole

8

27

60035696

Duct, cabling

2

28

13119701

Cabinet, electric control

1

29

A241600000022

Rail, clamp

1

30

A241200000220

Breaker, plastic housing

1

31

A242000000381

Teminal, wiring

7

32

B241300000022

Fuse

2

33

B241300000021

Fuse

2

34

B241300000024

Fuse

3

35

23003013

Jumper, adjacent

6

36

B240700000399

Relay, intermediate

4

37

B240700000395

Seat, relay

4

38

B240700000114

Relay, intermediate

1

39

B240700000125

Relay seat

1

40

B241600000002

Clip

2

41

A210210000015

Screw

60

42

A239900000051

Strap, nylon

80

43

60016006

Lamp, working

1

44

B241200000582

Receptacle, 2-position

1


















Item No.

Part No.

Description

Qty.

45

A249900001139

Lock, 2-position Receptacle

1

46

B249900000288

Pin

1

47

B241200000590

Plug, 2-position

1

48

B241200000584

Lock, 2-position Plug

1

49

B229900001093

Socket

1




















Item No.

Part No.

Description

Qty.

1

B240600000031

Sensor, temperature

1

2

A210434000007

Washer

1

3

60120497

Tail, socket, 2-wire

1

4

B241200000582

Receptacle, 2-position

1

5

B249900000288

Pin

2

6

A249900001139

Lock, 2-position Receptacle

1
























Item No.

Part No.

Description

Qty.

1

60040547

Sensor, liquid level

1

2

B241000000018

Receptacle, 2-position

1

3

B241000000002

Pin

2


























Item No.

Part No.

Description

Qty.

1

60213973

Battery

2

2

12495271

Plate, pressure, battery

1




















Item No.

Part No.

Description

Qty.

1

60232826

Lamp, working

2

2

B241100000447

Lamp, turn signal, LED

2

3

B241200000582

Receptacle, 2-position

2

4

A249900001139

Lock, 2-position Receptacle

2

5

B249900000288

Pin

4

6

B241200000590

Plug, 2-position

2

7

B241200000584

Lock, 2-position Plug

2

8

B229900001093

Socket

4
















Item No.

Part No.

Description

Qty.

1

60227844

Seat, fuse

2

2

60227841

Fuse

1

3

60229191

Fuse

1

4

60154909

Copper tube terminals

4

5

60227845

Seat, fuse

1

6

60227843

Fuse

1

7

60227846

Cover, fuse

1
