Body,container reach stacker, SRSC45H1 WGL





Item No.

Part No.

Description

Qty.

1

60222775

Spring

1

2

60222776

Valve, bypass

1

3

60222777

Core, filter

1
























Item No.

Part No.

Description

Qty.

1

B230103004966

Hose, rubber

1

2

A210204000354

Screw

28

3

B210780000244

Flange, Split

14

4

B230101000215

O-ring

7

5

B230103004967

Hose, rubber

1

6

B230103004968

Hose, rubber

1

7

B230103007338

Hose, rubber

1

8

13288352

Group, valve, telescopic

1

9

A210204000337

Screw M12×30GB70.110.9

8

10

B230103005881

Hose, rubber

2

11

B230103000342

Hose, rubber

1

12

A810312990137

Assembly, steel pipe

1

13

A810312019055

Assembly, steel pipe

1

14

A810312019056

Assembly, steel pipe

1

15

B230103004767

Hose, rubber

2

16

60112028

Hose, rubber

1

17

13290418

Block, valve, pitching, right

1

18

A210204000255

Screw M12×55GB70.1 12.9

8

19

60247914

O-ring

2

20

13290413

Group, valve, pitching, left

1

21

60016784

Hose, rubber

2

22

A810201060300

System, hydraulic, antiswing

1
























Item No.

Part No.

Description

Qty.

23

12344078

Sleeve, protective, rubber hose

1

24

A210401000002

Washer

8
















Item No.

Part No.

Description

Qty.

1

13288264

Block, valve, telescopic

1

2

B210770000003

Connector, pressure measuring

2

3

B210399000003

Plug

7

4

B220401000544

Valve, logic

1

5

B210780001384

Plug

5

6

B220401000541

Valve, reversal, electromagnetic

1

7

B210780000036

Connector

1

8

B220401000497

Valve, reversal, electromagnetic

1

9

A210609000121

O-ring

2

10

B220401000540

Valve, check

2

11

B220401000537

Valve, reversal, electromagnetic

2

12

B220401000533

Valve, balance

1

13

B220401000546

Valve, trottle, one-way

1

14

12217657

Plug, screw, damping

1

15

B210399000005

Plug

1

16

12217584

Plug, screw, damping

1

17

B210780000201

Plug

4

18

B210780000799

Plug

1
























Item No.

Part No.

Description

Qty.

1

60234608

Coil

1
















Item No.

Part No.

Description

Qty.

1

B220401000542

Valve, reversal, electromagnetic

1

2

12853387

Block, valve, lifting, right

1

3

B210780000799

Plug

1

4

B210780000201

Plug

2

5

12217584

Plug, screw, damping

2

6

B220401000544

Valve, logic

1

7

12066238

Plug, damping

1

8

60155029

Valve, overflow

1

9

B220401000541

Valve, reversal, electromagnetic

1

10

B210780000896

Plug

1

11

B210780000899

Fitting, Adapter

1

12

B220401000540

Valve, check

2

13

B210399000003

Plug

6






















Item No.

Part No.

Description

Qty.

1

B220401000541

Valve, reversal, electromagnetic

1

2

12853385

Block, valve, lifting, left

1

3

60155029

Valve, overflow

1

4

12066238

Plug, damping

1

5

B220401000544

Valve, logic

1

6

B210780000201

Plug

3

7

12217584

Plug, screw, damping

2

8

B210780000799

Plug

1

9

B210399000003

Plug

6

10

B220401000542

Valve, reversal, electromagnetic

1

11

B220401000540

Valve, check

2

12

B210780000899

Fitting, Adapter

1

13

B210780000896

Plug

1














1

B230103000335

Hose, rubber

2

2

A832511054000

Hose, rubber

2

3

B210780000042

Connector

5

4

B210780000025

Fitting, Elbow

2

5

13336502

Group, antiswing valve

1

6

B230103000098

Hose, rubber

1

7

B230103000798

Hose, rubber

2

8

B210780000421

Connector

2

9

B210780000329

Fitting, Adapter

1

10

21018928

Valve, one-way

1

11

B210780000266

Fitting, Adapter

2

12

B210780000017

Fitting, Tee

1
