LONKING forklift spare parts AI

编码 Code	起升高度 Lifting H	内门架 Inner mast	中门架 Middle mast	外门架 Outer mast	链条编码 Code,chain	链条节数 Chain,leaf	备注 Remark
30080913045	4000	30082081605	30082085347	30080082710	30080080214	93
30080913046	4350	30082081606	30082085348	30080082711	30080080215	101
30080913044	4500	30082081604	30082085346	30080082899	30080080204	103	标准
30080913047	4800	30082081607	30082085349	30080082712	30080080219	109
30080913048	5000	30082081608	30082085350	30080082713	30080080205	113
30080913049	5400	30082081609	30082085351	30080082714	30080080233	121
30080913050	6000	30082081610	30082085352	30080082715	30080080225	131
30080913051	6500	30082081611	30082085353	30080082716	30080080216	143

序号 Item No	编码 Code	图号 Part No	零部件名称 Description	数量 Q’ty	备注 Remark
1	30082082901	LG0030DIII.10B.01	外门架焊合 Inner mast	1
2	30082085336	LG0030DIII.10B.02	中门架焊合 Middle mast	1
3	30082081861	LG0030DIII.10B.03	内门架焊合 Outer mast	1
4	30080025001	LG0020D.10.03	销轴焊合 Pin shaft weldment	2
5	51204091014	GB/T5783	螺栓M8×20 Bolt M8×20	2
6	51401090107	GB/T93	垫圈8 Washer 8	2
7	51421090115	GB/T97.1	垫圈8 Washer 8	2
8	56201000301	JB/T7940.1	油杯M10×1 Oil cup M10×1	4
9	52001000302	GB/T12949	滑动轴承30×34×25 Slide bearing 30X34X25	2
10	30082185701	LG0030D.10B.02-001	链轮 Chain wheel	2
11	51453350107	GB/T894.1	挡圈40 Snap ring 40	4
12	30082141002	LG0030D.10-003	滚轮 Roller	8
13	60980000833	LG0030D.10.06.01-002	螺钉M20X1.5X17 Screw M20×1.5×17	8
14A	30082081401	LG0030DIII.10.02	滚轮总成 Roller assembly	4	包含14 – 20项
14	30080182801	LG0030D.10.16-003	止松片 Stop ring	8
15	30082154813	LG0030DIII.10.02-001	调整垫 Adjustment gasket	4
16	30082113902	LG0030DIII.10.02-002	橡胶垫 Rubber gasket	4
17	30080180401	LG0030D.10.16-002	防尘片 Dust ring	8
18	51453420107	GB/T894.1	挡圈55 Snap ring 55	8
19	30082141005	LG0030DIII.10.02-003	滚轮 Roller	4
20	51517092302	GB/T119.2	销5×10 Pin 5×10	8
21	30082141003	LG0030D.10-004	滚轮 Roller	4
22A	30082141004	LG0030D.10.17	滚轮总成 Roller assembly	4	含14,17，18，22
22	30004141000	LG0030D.10.17-001	滚轮 Roller	4
23	30082118500	LG0030D.10-005	端盖 End cover	2
24	30082184500	LG0030D.10-006	轴衬 Bushing	2
25	51207132014	GB/T5786	螺栓M16×1.5×70 Bolt M16×1.5×70	4
26	51401130107	GB/T93	垫圈16 Washer 16	4
27	30082080321	LG0030D.10B.02.04	链条总成LH1623 Chain assembly	2
28	30082185100	LG0030D.10-007	滑块 Slide block	4
29	30082154800	LG0030D.10-008	调整垫 Adjustment gasket	4	t=0.5
	30082154805	LG0030D.10-008	调整垫 Adjustment gasket	4	t=1.0
	30082154806	LG0030D.10-008	调整垫 Adjustment gasket	4	t=2.0
30	30082113903	LG0030D.10-020	橡胶垫 Rubber gasket	4
31	60980005823	LG0030D.10-021	红色保护套 Red sheath	4

编码 Code	起升高度 Lifting H	内门架 Inner mast	中门架 Middle mast	外门架 Outer mast	链条编码 Code,chain	链条节数 Chain,leaf	备注 Remark
30082913055	4000	30082081859	30082085334	30082082899	30082080303	69
30082913056	4350	30082081860	30082085335	30082082900	30082080304	75
30082913057	4500	30082081861	30082085336	30082082901	30082080321	77	标准
30082913063	4700	30082081869	30082085344	30082082911	30082080323	79
30082913058	4800	30082081862	30082085337	30082082902	30082080305	81
30082913059	5000	30082081863	30082085338	30082082903	30082080306	85
30082913060	5400	30082081864	30082085339	30082082904	30082080307	89
30082913064	5500	30082081870	30082085345	30082082912	30082080308	91
30082913061	6000	30082081865	30082085340	30082082905	30082080310	99
30082913062	6500	30082081866	30082085341	30082082906	30082080311	107

序号 Item No	编码 Code	图号 Part No	零部件名称 Description	数量 Q’ty	备注 Remark
1	30082083101	LG0035DIII.10B.01	外门架焊合 Outer mast	1
2	30082085368	LG0035D.10BI.02	中门架焊合 Middle mast	1
3	30082081632	LG0035D.10BI.03	内门架焊合 Inner mast	1
4	30080025001	LG0020D.10.03	销轴焊合 Pin shaft weldment	4
5	51204091014	GB/T5783	螺栓M8×20 Bolt M8×20	4
6	51401090107	GB/T93	垫圈8 Washer 8	4
7	51421090115	GB/T97.1	垫圈8 Washer 8	4
8	52001000302	GB/T12949	滑动轴承30×34×25 Slide bearing 30X34X25	2
9	51207132014	GB/T5786	螺栓M16×1.5×70 Bolt M16×1.5×70	4
10	51401130107	GB/T93	垫圈16 Washer 16	4
11	30082118500	LG0030D.10-005	端盖 End cover	2
12	30082184500	LG0030D.10-006	轴衬 Bushing	2
13	56201000301	JB/T7940.1	油杯M10×1 Oil cup M10×1	4
14	60980005823	LG0030D.10-021	红色保护套 Red sheath	4
15	30082141002	LG0030D.10-003	滚轮 Roller	4
16	51453420107	GB/T894.1	挡圈55 Snap ring 55	8
17	30082081402	LG0035DⅢ.10.05	滚轮总成 Roller assembly	4
18	51204111514	GB/T5783	螺栓M12×45 Bolt M12×45	8
19	51401110107	GB/T93	垫圈12 Washer 12	16
20	30086106401	LG0045D.10-008	垫圈 Washer	8
21	30086118200	LG0060DT.10-008	垫片 Gasket	16
22	30082141003	LG0030D.10-004	滚轮 Roller	4
23A	30086081403	LG0040D.10I.05	滚轮总成 Roller assembly	2	包含23 – 25项
23	30082141000	LG0035DIII.10.07-001	滚轮 Roller	2
24	51453240107	GB/T894.1	挡圈25 Snap ring 25	2
25	30086180705	LG0040D.10Ⅰ.05-001	滚轮轴 Roller shaft	2
26	51204111414	GB/T5783	螺栓M12×40 Bolt M12×40	8
27	30086106400	LG0060DT.10-007	垫圈 Washer	8
28	30082141010	LG0025BIII.10.04	滚轮 Roller	2
29	30082185702	LG0035D.10-003	链轮 Chain wheel	2
30	51453370107	GB/T894.1	挡圈45 Snap ring 25	2
31	30082080403	LG0040D.10BⅠ.06	链条总成LH1634 Chain assembly	2
32	30082185100	LG0030D.10-007	滑块 Slide block	4
33	30082154800	LG0030D.10-008	调整垫 Adjustment gasket	4	t=0.5
	30082154805	LG0030D.10-008	调整垫 Adjustment gasket	4	t=1.0
	30082154806	LG0030D.10-008	调整垫 Adjustment gasket	4	t=2.0

编码 Code	起升高度 Lifting H	内门架 Inner mast	中门架 Middle mast	外门架 Outer mast	链条编码 Code,chain	链条节数 Chain,leaf	备注 Remark
30082913098	3600	30082081629	30082085365	30082082998	30082080400	65
30082913099	4000	30082081630	30082085366	30082082999	30086080424	71
30082913100	4350	30082081631	30082085367	30082083100	30086080425	77
30082913101	4500	30082081632	30082085368	30082083101	30086080403	79	标准
30082913103	4800	30082081634	30082085370	30082083103	30082080419	83
30082913104	5000	30082081635	30082085371	30082083104	30086080420	87
30082913105	5400	30082081636	30082085372	30082083105	30086080402	91
30082913107	6000	30082081638	30082085374	30082083107	30086080404	99
30082913108	6500	30082081639	30082085375	30082083108	30086080416	107

序号 Item No	2–2.5T货叉编码 Code,fork(2-2.5T)	2–2.5T货叉规格 Model,fork(2-2.5T)	备注 Remark
1	30082081200	920×120×40
2	30082081201	1070×120×40	标准
3	30082081202	1220×120×40
4	30082081203	1370×120×40
5	30082081204	1520×120×40
6	30082081205	1670×120×40
7	30082081206	1820×120×40
8	30082081207	1900×120×40

序号 Item No	3T货叉编码 Code,fork(2-2.5T)	3T货叉规格 Model,fork(2-2.5T)	备注 Remark
1	30082081208	1070×125×45	标准
2	30082081209	1220×125×45
3	30082081210	1370×125×45
4	30082081211	1520×125×45
5	30082081212	1670×125×45
6	30082081213	1820×125×45
7	30082081214	1900×125×45
8	30082081215	2000×125×45


2	30080081010	LG0020DⅢ.10.02	货叉架焊合	Fork carrier weldment	1	标准
	30080081000	LG0020DⅢ.10A.03	货叉架焊合	Fork carrier weldment	1	二级全自由
	30080081012	LG0020DⅢ.10B.03	货叉架焊合	Fork carrier weldment	1	三级全自由
3	30082083500	LG0025D.10.02	挡货架焊合	Load retainer	1
4	51207121214	GB/T5783	螺栓M14×1.5×30	Bolt M14×1.5×30	8
5	51401130107	GB/T93	垫圈14	Washer 14	8
6	30082141010	LG0025BⅢ.10.04	滚轮	Washer	2
7	51204111614	GB/T5783	螺栓M12×50	Adjustment gasket	4
8	51401110107	GB/T93	垫圈12	Roller	5
9	30086106400	LG0060DT.10-007	垫圈	Washer 12	4
10	30086118200	LG0060DT.10-008	垫片	Bolt M12×50	4
11A	30082141004	LG0030D.10.17	滚轮总成	Roller assembly	4	包含11-14项
11	30004141000	LG0030D.10.17-001	滚轮	Roller	4
12	30080180401	LG0030D.10.16-002	防尘片	Dust ring	4
13	51453420107	GB/T894.1	挡圈55	Snap ring 55	4
14	30080182801	LG0030D.10.16-003	止松片	Stop ring	4
15	60980000833	LG0030D.10.06.01-002	螺钉M20X1.5X17	Screw M20×1.5×17	4
16	30082141006	LG0025BⅢ.10-002	滚轮	Roller	4
17	51139230205	GB/T70.1	螺钉M12×25	Screw M12×25	1

序号 Item No	编码 Code	图号 Part No	零部件名称 Description		数量 Q’ty	备注 Remark
1	30082083503	LG0030DⅢ.10.09	挡货架焊合	Load retainer weldment	1
2	51207121214	GB/T5786	螺栓M14×1.5×30	Bolt M14×1.5×30	8
3	51401130107	GB/T93	垫圈14	Washer 14	8
4	30082081208	LG0030D.10.03	货叉总成	Fork Assembly	2
5	30082081010	LG0030DⅢ.10B.04	货叉架焊合	Fork carrier weldment	1	三级全自由
	30082081008	LG0030DⅢ.10.04	货叉架焊合	Fork carrier weldment	1	标准
	30082081009	LG0030DⅢ.10A.02.03	货叉架焊合	Fork carrier weldment	1	二级全自由
6	30082141002	LG0030D.10-003	滚轮	Roller	4	包含8-14项
7	60980000833	LG0030D.10.06.01-002	螺钉M20X1.5X17	Screw M20×1.5×17	4
8A	30082081401	LG0030DⅢ.10.02	滚轮总成	Roller assembly	4
8	30080182801	LG0030D.10.16-003	止松片	Stop ring	4
9	30082154813	LG0030DⅢ.10.02-001	调整垫	Adjustment gasket	4
10	30082113902	LG0030DⅢ.10.02-002	橡胶垫	Rubber gasket	4
11	30080180401	LG0030D.10.16-002	防尘片	Dust ring	4
12	51453420107	GB/T894.1	挡圈55	Snap ring 55	4
13	30082141005	LG0030DⅢ.10.02-003	滚轮	Roller	4
14	51517092302	GB/T119.2	销5×10	Pin 5×10	8
15	51401110107	GB/T93	垫圈12	Washer 12	1
16	51139230205	GB/T70.1	螺钉M12×25	Screw M12×25	1

3.5T标准/二级全自由

序号 Item No	货叉编码 Code,fork	货叉规格 Model,fork	备注 Remark
1	30082081216	1070×125×50	标准
2	30082081217	1220×125×50
3	30082081218	1370×125×50
4	30082081219	1520×125×50
5	30082081220	1670×125×50
6	30082081221	1820×125×50
7	30082081222	1900×125×50
8	30082081223	2000×125×50

序号 Item No	编码 Code	图号 Part No	零部件名称 Description		数量 Q’ty	备注 Remark
A	16600013740	LG0025D.10.07	右起升缸	Right lift cylinder	1	高度3000
B	16600013730	LG0025D.10.09	左起升缸	Left lift cylinder	1	高度3000
1	51204133714	GB/T5783	螺栓M16X40	Bolt M16×40	2
2	51401130107	GB/T93	垫圈16	Washer 16	2
3	30082154801	LG0030D.10-010	调整垫	Adjustable gasket	2
4	30082109601	LG0030D.10-011	卡箍	Clamp	2
5	30082185000	LG0030D.10-012	箍座	Clamp seat	2
6	30082113900	LG0030D.10-013	橡胶垫	Rubber gasket	2
7	51207115614	GB/T5786	螺栓M12X1.25X50	Bolt M12×1.25×50	2
8	51309000519	GB/T6171	螺母M12X1.25	Nut M12×1.25	2
9	51309000319	GB/T6171	螺母M10X1.25	Nut M10×1.25	4
10	51401100107	GB/T93	垫圈10	Washer 10	4
11	51421100115	GB/T97.1	垫圈10	Washer 10	4
12	56193000301		防尘圈40X52X7	Dust ring 40×52×7	2
13	56187000601		轴用密封圈40X50X7	Seal ring 40×50×7	2
14	36600032010	LGG020SP300H-01	缸盖	Cylinder cover	2
15	51106211007	GB/T77	螺钉M8X8	Screw M8×8	4
16	36600321010	LGG030SP300H-02	锁紧垫	Lock gasket	4
17	52500000201		钢背轴承40X44X30	Steeled -backed bearing	2
18	56194002001	EKM	0形圈57X3	O-ring 57×3	2
19	36600371010	LGG020SP300H-02	支撑套	Supporting sheath	2
20	56145077904	GB/T3452.1	O形圈40X1.8	O-ring 40×1.8	2	高度≥4000时用
21	36600071010	LGG020SP400H-05	间隔套	Spacer	2	4000≤高度≤5000
	36600071020	LGG020SP550H-05	间隔套	Spacer	2	高度≥5500时用
22	36600041040	LGG020SP300H-03	活塞杆	Piston rod	2
23	56199008101		支承环45X50X20	Pivot ring 45×50×20	2
24	56192014901		挡圈40X50X3	Snap ring 40×50×3	2
25	56191003701		活塞密封圈50X40X7	Seal ring 50×40×7	2
26	36600012040	LGG020SP300LH.01	左缸体	Left cylinder body	1	高度3000
27	36600013040	LGG020SP300RH.01	右缸体	Right cylinder body	1	高度3000
28	51513131502	GB/T119.1	圆柱销6X26	Pin 6×26	2
29	36600021010	LGG020SP300H-04	活塞	Piston	2
30	51466240119	GB/T895.1	挡圈25	Snap ring 25	2
31	30082135101	LG0030D.10-009	轴套	Bushing	2
32	51421110115	GB/T97.1	垫圈12	Washer 12	2
33	51401110107	GB/T93	垫圈12	Washer 12	2
34	51207115214	GB/T5786	螺栓M12X1.25X30	Bolt M12×1.25×30	2

起升高度 Lifting height	左缸编码 Cylinder code(L)	右缸编码 Cylinder code(R)	左缸体 Left cylinder body	右缸体 Right cylinder body	活塞杆 Rod,piston	备注 Remark
2000	16600013670	16600013680	36600012010	36600013010	36600041010
2500	16600013690	16600013700	36600012020	36600013020	36600041020
2750	16600400750	16600400760	36600018000	36600018020	36600047200
3000	16600013730	16600013740	36600012040	36600013040	36600041040	标准
3300	16600013750	16600013760	36600012050	36600013050	36600041050
3500	16600013770	16600013780	36600012060	36600013060	36600041060
3750	16600400770	16600400780	36600018010	36600018030	36600047210
4000	16600013990	16600013820	36600012080	36600013080	36600041080
4250	16600400330	16600400340	36600012090	36600013090	36600041090
4500	16600013830	16600013840	36600012100	36600013100	36600041100
4750	16600013850	16600013860	36600012110	36600013110	36600041110
5000	16600013880	16600013870	36600012120	36600013120	36600041120
5500	16600013890	16600013900	36600012130	36600013130	36600041130
6000	16600400310	16600400320	36600012140	36600013140	36600041140

序号 Item No	编码 Code	图号 Part No	零部件名称 Description		数量 Q’ty	备注 Remark
A	16600401100	LG0030D.10.11	起升油缸	Lift cylinder	2	高度3000
1	36600041200	LGG030SP300H-04	活塞杆	Piston rod	2
2	51466240119	GB/T895.1	挡圈25	Snap ring 25	2
3	36600021030	LGG030SP300H-05	活塞	Piston	2
4	56199008201		支承环51X56X20	Pivot ring 51×56×20	2
5	56192015101		挡圈45X56X3	Snap ring 45×56×3	2
6	56191003901		活塞密封圈56X45X8	Seal ring 56×45×8	2
7	51513131502	GB/T119.1	圆柱销10X26	Cylindrical pin 10×26	2
8	36600012950	LGG030SP300H.01	缸体	Cylinder body	2
9	36600371020	LGG030SP300H-03	支撑套	Support sheath	2
10	56900009202	AS568	O形圈63.17X2.62	O-ring 63.17×2.62	2
11	52500002801		钢背轴承45X50X30	Steel-backed bearing	2
12	51106211007	GB/T77	螺钉M8X8	Screw M8×8	4
13	36600321010	LGG030SP300H-02	锁紧垫Φ6X3	Lock gasket Φ6×3	4
14	36600032020	LGG030SP300H-01	缸盖	Cylinder cover	2
15	56187010501		轴用密封圈45X55X7	Seal ring 45×55×7	2
16	56185000401		防尘圈45X53X6	Dust ring 45×53×6	2
17	36600071040	LGG030SP400H-07	间隔套	Spacer	2	4000≤高度≤5000
	36600071050	LGG030SP550H-07	间隔套	Spacer	2	高度≥5500时用
18	56145011401	GB/T3452.1	O形圈43.7X2.65	O-ring 43.7×2.65	2	高度≥4000时用
19	51401130107	GB/T93	垫圈16	Washer 16	2
20	30082154801	LG0030D.10-010	调整垫	Adjustable gasket	2
21	51204133714	GB/T5783	螺栓M16X40	Bolt M16×40	2
22	30082135101	LG0030D.10-009	轴套	Sleeve	2
23	51207115314	GB/T5786	螺栓M12X1.25X35	Bolt M12×1.25×35	2
24	51421110115	GB/T97.1	垫圈12	Washer 12	2
25	51401110107	GB/T93	垫圈12	Washer 12	2
26	30082109601	LG0030D.10-011	卡箍	Clamp	2
27	51421100115	GB/T97.1	垫圈10	Washer 10	4
28	51309000319	GB/T6171	螺母M10X1.25	Nut M10×1.25	4
29	51401100107	GB/T93	垫圈10	Washer 10	4
30	30082185000	LG0030D.10-012	箍座	Clamp seat	2
31	30082113900	LG0030D.10-013	橡胶垫	Rubber gasket	2
32	51207115614	GB/T5786	螺栓M12X1.25X50	Bolt M12×1.25×50	2
33	51309000519	GB/T6171	螺母M12X1.25	Nut M12×1.25	2

编码 Code	起升高度 Lifting height	活塞杆 Postion rod	缸体 Cylinder body	备注 Remark
16600401020	1820	36600041160	36600012910
16600401040	2000	36600041170	36600012920
16600401060	2500	36600041180	36600012930
16600401080	2700	36600041190	36600012940
16600401770	2750	36600047170	36600017980
16600401100	3000	36600041200	36600012950	标准
16600401120	3300	36600041210	36600012960
16600401140	3500	36600041220	36600012970
16600401160	3700	36600041230	36600012980
16600401780	3750	36600047180	36600017990
16600401180	3800	36600041240	36600012990
16600401200	4000	36600041250	36600013000
16600401220	4250	36600041260	36600013770
16600015860	4500	36600041270	36600013780
16600015880	4750	36600041280	36600013790
16600015900	5000	36600041290	36600013800
16600015920	5500	36600041300	36600013810
16600015940	6000	36600041310	36600013820
