60140031 Turboshaft Dana

60140031 Turboshaft Dana

1 60099603 guide wheel seat screw DANA 7
2 60099701 Locking washer DANA 7
3 60099604 Guide wheel seat assembly DANA 1
4 60099582 Torque converter oil inlet pipe DANA 1
5 60099773 Turbine shaft oil seal DANA 1
6 60099730 Bearing positioning ring DANA 1
7 60099729 Bearing washer DANA 1
8 60121019 Bearing DANA 1
9 60099760 Guide wheel seat oil seal DANA 1
10 60099759 Oil retaining plate oil seal DANA 1
11 60099758 Oil deflector seal DANA 1
12 60099490 Oil retaining plate DANA 1
13 60099599 Oil retaining plate snap ring DANA 1
14 60099546 Turbine shaft rear bearing DANA 1

60138822 动力输入端齿轮组 Dana

1 60099707 涡轮轴 DANA 1
2 60099561油泵主动齿轮 DANA 2

60139513 轮毂组件 Dana (1/2)

1 60099600 guide wheel DANA 1
2 60099730 Bearing positioning ring DANA 1
3 60099602 guide wheel spacer pin DANA 1
4 60099510 Turbo DANA 1
5 60099704 turbine hub DANA 1
6 60099705 Turbine hub rear positioning ring DANA 1
7 60099677 Front bearing positioning ring DANA 1
8 60099706 Turbine hub screw DANA 10
9 60099563 Turbine hub screw lock plate DANA 5
10 60099511 Pump wheel DANA 1
11 60099753 Pump impeller cover to pump impeller O-ring DANA 1
12 60099574 Impeller cover to impeller screw DANA 32
13 60099700 Locking Washer DANA 32
14 60099576 Pump wheel hub DANA 1
15 60099755 Pump wheel hub O-ring DANA 1
16 60099578 Pump wheel hub screw DANA 8
17 60099579 Pump wheel hub screw bushing DANA 1
18 60099533 Pump wheel hub bearing DANA 1
19 60099580 Pump wheel hub bearing snap ring DANA 1
20 60099512 Pump impeller cover DANA 1
21 60099545 turbine hub bearing DANA 1
22 60099754 Pump impeller cover Bearing cover O-ring DANA 1

23 60099729 Bearing washer DANA 1
24 60099730 Bearing positioning ring DANA 1
25 60099575 Pump impeller cover bearing cover DANA 1
26 60099601 guide wheel spacer DANA 1
