11505874 Radar,reversing,visible,3m

11505874 Radar,reversing,visible,3m

1 60077916 Rador,reversing,visible,improved,3m 1
2 B241200000582 Sleeve, protection, plug, two-wire 1
3 B241200000590 Sleeve, protective, socket, two-wire 1
4 A249900001139 Lock, secondary pole, 2-wire, pin 1
5 B241200000584 Lock, secondary pole, 2-line (socket) 1
6 B249900000288 Pin 2
7 B229900001093 Socket 2
8 24002246 Screw 6
9 11505982 Support,reversing rador 1

10117173 Assembly, nameplate (1/4)

1 10061340 Label, safety load 2
2 10997589 Label, stand is clear in moving 1
3 A820101990552 Label, lifting point 14
4 A210506000018 Rivet 64
5 10026017 Label, no climbing 2
6 12030342 Label, warning, anti-pinching 2
7 10027027 Label, air pressure of tyre 4
8 12120439 Label, instruction, max. oil level 3
9 12120438 Label, instruction, min. oil level 2
10 12074911 Label, lubrication points 1
11 10026753 Label, hydraulic pressure 1
12 12120416 Decal, maintenance 1
13 12120475 Label, hydraulic oil tank 1
14 12120419 Label, warning, no jumping off 2
15 10580064 Label, warning, spreader 2
16 10706180 Label, watchful of the hanged objects 1
17 12074828 Label, warning, tyre 4

18 10706189 Label, warning, no passing by 1
19 12033671 Label, warning, anti-pinching 1
20 10580066 Nameplate 1
21 12120478 Label, CE 1
22 12120429 Label, brake oil tank 1
23 A820101050790 Label, warning, prevent electricity attack 1
24 A820101050794 Label, warning, touch is forbidden 1
25 12120482 Label, power supply switch 1
26 12120466 Label, battery 1
27 12120470 Label, electric control cabinet 1
28 12120432 Label, fuel tank 1
29 A820101050797 Label, warning, smoking is forbidden 1
30 10178073 Label, oil-water separator 1
31 12120424 Label, warning, do not open 2
32 A820101050799 Label, warning, person not concerned are not allowed to enter 2
33 A820101050798 Decal, warning, hot surface 1

34 12030062 Label, mind your head 2
35 A820601990572 VI Logo,trailer-mounted concrete pump 1
36 A820601990595 SANY logo 1
37 10026322 Film, warning, right 2
38 12124672 Label, warning, no stay 2
39 12033760 Label, anti-cutting 1
40 11043480 Label, reminder, check the joint bearing 2
41 10706179 Label, warning, watchful of the cables 1
42 12033769 Label, warning, mind the fallen parts 1
43 10049665 Sticker, antislip 4
44 A820101050793 Decal, warning, fan 1
45 12028685 Label, caution for hand injury by machine 1
