60138864 Unit, engine oil filter

60138864 Unit, engine oil filter

1 60132096 Oilfilterhousing 1
2 60131061 Flangescrew 2
3 60129824 Cover 1
4 60092706 O-ring 1
5 60130301 Reducingvalve 1
6 60132452 Sealingring 1
7 60130987 Plug 2
8 60130791 Gasket 2
9 60130635 Spring 1
10 60130288 Valve 1
11 B229900002947 Plug,oil 2
12 60131442 Nipple 1
13 60092408 Plug 1
14 60130286 Valve 1
15 60129811 Cover 1
16 60130299 Reducingvalve 1
17 60130278 Valve 1
18 60130627 Spring 1
19 60130279 Valve 1
20 60132463 Snapring 1
22 60131809 Screw 2
23 60130030 Capplug 1

24 60094293 Bolt,flange 1
25 60094285 Bolt, flange 5
26 60092482 Bolt,flange 3
27 60094263 Washer 1
28 60132385 O-ring 3
29 60129818 Cover 1
30 60094486 O-ring 2
31 60131435 Nipple 2
33 60131466 Nipple 4
34 60129815 Cover 2
35 60131437 Nipple 1
36 60132087 Oilhose 1
37 60132086 Oilhose 1
38 60131467 Nipple 2
39 60131266 Clamp 4
41 60010662 Bolt 2
42 60138897 Oil filter 2
43 60139075 Gasket 2
44 B222100000137 Filter,oil 1
45 60139076 Gasket 1
47 60131443 Nipple 1
48 60140109 Oil filter housing 1

50 60092773 Plug 2
51 60092410 Plug 2
52 B220401000677 Pad, oil return valve 2
53 60140110 Oil filter housing 1
54 60138496 Hose 1
55 60140107 Oil hose 1
56 60109554 Bolt, hollow 2
58 60138730 Reducing valve 2
59 60092371 Clamp,fixed 4
60 60094396 Bolt 3
62 60085707 Washer 1

60140111 Components, oil filter seat

1 60132089 Oilfilterhousing 1
2 60132095 Oilfilterhousing 1
3 60084546 Screw,support,lock block 2
4 60129824 Cover 1
5 60092706 O-ring 1
6 60130298 Pistoncoolingvalve 1
7 60132452 Sealingring 1
8 60130987 Plug 2
9 60130791 Gasket 2
10 60130636 Spring 2
11 60130288 Valve 2
12 60085707 Washer 1
13 60092408 Plug 1
14 B229900002947 Plug,oil 2
15 60131442 Nipple 2
16 60131443 Nipple 1
17 60130287 Valve 1
18 60129811 Cover 1
19 60130271 Deliveryvalve 1
20 60130279 Valve 1
21 60130628 Spring 1
22 60130276 Valveguide 1

23 60132463 Snapring 1
24 60092706 O-ring 1
25 60131809 Screw 2
26 60130030 Capplug 1
27 60094263 Washer 1
28 60094285 Bolt, flange 5
29 60092482 Bolt,flange 3
30 B222100000136 Filter,oil 2
31 B222100000137 Filter,oil 1
32 60129817 Cover 1
33 60084546 Screw,support,lock block 2
34 60130989 Plug 1
35 60129757 Sender 1
