60139806 Cylinder block

60139806 Cylinder block

1 60131902 Cylinderblock 1
2 60131906 Mainbearingcap,front 1
3 60132321 Mainbearingcap 5
4 60131278 Mainbearingcap,rear 1
5 60132031 Pin 1
6 60131717 Screw 14
7 60092369 Plug,cover 3
8 60131003 Plug 1
9 60094252 Sleeve,guide 2
10 60087302 Washer 3
11 60130991 Plug 1
12 60130984 Plug 2
13 60089108 Gasket 2
14 60092773 Plug 2
15 60129819 Cover 1
16 60094287 Bolt,flange 2
17 60092718 O-ring 1
18 60131080 Flangescrew 4
19 60130892 Liftingeye 1
20 60085706 Washer 2
21 60092772 Plug 2
22 60089108 Gasket 2

23 60087996 Joint 1
24 60132979 Protectivecap 1
25 60094286 Bolt, flange 1
26 60130710 Gasket 1
27 60132393 O-ring 4

60139179 Shell, flywheel

1 60131117 Flywheelhousing 1
2 60085953 Ring,seal 1
3 60130986 Plug 2
4 60092473 Bolt,flange 2
5 60092472 Bolt,flange 8
6 60092599 Bolt 2
7 60129829 Cover 1
8 60131808 Screw 3
9 60132448 Sealingring 1
10 60130951 Plug 1
11 60131962 Lockwasher 1
12 60092391 Screw 2
13 60086208 O-ring,hose,turbocharger 1
14 60130952 Plug 1
15 60131062 Flangescrew 1
16 60131963 Lockwasher 1

60139819 Air valve Ass

1 60094451 Shaft,rocker arm 1
2 60130996 Plug 2
3 60131474 Rockerarm,intake 6
4 60094386 Nut 1
5 60087247 End,ball 1
6 60096165 Ball socket 1
7 60094487 O-ring 1
8 60131908 Ballseat 1
9 60129724 Valvecaliper 12
10 60100181 Air intake valve 12
11 60086203 Seal,oil,valve,air 24
12 B210619000004 Spring,valve,exhaust 12
13 60087296 Valve spring washer 24
14 60131861 Valvecotter 48
15 60132062 Rockerarm,injector 6
16 60087248 End,ball 1
17 60088003 Nut 1
18 60129876 Nozzle 2
19 60132059 Rockerarm,exhaust 6
20 60087247 End,ball 1
21 60094386 Nut 1
22 B210619000005 Spring,valve,air 24

23 60086185 Valve,drain 12
24 60094152 Leaf sprin 6
25 60131051 Flangescrew 7
