Part No. |
Description |
|
11804806 |
Sleeve, protective, rubber |
|
A210111000234 |
Bolt |
|
13246350 |
Support, sliding, telescopic cylinder |
|
13147817 |
Assembly, telescopic cylinder |
|
A820301020692 |
Shaft, telescopic cylinder |
|
A820102010496 |
Gasket, adjusting, telescopic cylinder |
|
A810312100021 |
Frame, connecting, telescopic cylinder |
|
A820101312408 |
Baffle, shaft end |
|
A210111000039 |
Bolt |
|
A820101312407 |
Baffle, shaft end |
|
A210111000107 |
Bolt |
|
A820301020670 |
Shaft, connecting |
|
11865288 |
Shaft, telescopic cylinder |
|
11447999 |
Plate, pressure, coupling shaft |
|
13045939 |
Bracket, slot, hose |
|
A210204000165 |
Screw M16×40GB70.1 |
|
A210111000090 |
Bolt M8x25 |
|
A210401000017 |
Washer Lock M8 |
|
A210307000012 |
Nut |
|
A820101312460 |
Groove, drag-chain |
|
11448585 |
Section, telescopic, arm |
|
11044952 |
Sleeve, eccentric |
|
Part No. |
Description |
|
A210401000006 |
Washer Lock M20 |
|
B229900003376 |
Chain, drag |
|
A210612000006 |
Bearing, joint |
|
A810312110031 |
Shaft, pin |
|
10859964 |
Bearing, sliding |
|
10202942 |
Cylinder, damping |
|
11447998 |
Shaft, coupling |
|
A210204000158 |
Screw M16×30GB70.1 |
|
11446526 |
Bearer, front, telescopic cylinder |
|
13245284 |
Pin, clip |
|
Part No. |
Description |
|
A210416000050 |
Ring, retaining |
|
A221500000265 |
Bearing, joint |
|
A210804000002 |
Zerk, Grease |
|
A210307000001 |
Nut |
|
10198715 |
Cushion, protective |
|
10198714 |
Plate, protective |
|
A210111000042 |
Bolt |
|
A210204000202 |
Screw |
|
10198716 |
Plate, protective |
|
10198717 |
Cushion, protective |
|
10201638 |
Components, cylinder barrel |
|
12265862 |
Ring, retaining |
|
60208499 |
Bearing, oilless |
|
60198061 |
Ring, bamper |
|
60247456 |
Ring, seal, B3 |
|
60208089 |
Ring, dustproof |
|
A210609000028 |
O-ring 212×7GB3452.1 |
|
10204974 |
Ring, retaining |
|
A210609000112 |
O-ring 212×5.3GB3452.1 |
|
12956405 |
Sleeve, guide |
|
A880801010085 |
Screw |
|
10204971 |
Nut |
|
Part No. |
Description |
|
B230101001559 |
Ring, anti-pollution |
|
B230101001639 |
Guide ring |
|
60249669 |
Ring, seal, B7 |
|
B230101000021 |
Ring, seal, OK |
|
A210609000124 |
O-ring 150×5.3GB3452.1 |
|
A210609000359 |
O-ring |
|
A210206000004 |
Screw M8×16GB77 |
|
A210661000016 |
Ball, steel |
|
13178277 |
Nut, lock |
|
13178276 |
Piston |
|
13178280 |
Assembly, piston rod |
|
10204970 |
Nut |
|
10201646 |
Ring, ear |
|
Part No. |
Description |
|
A820202005521 |
Bushing |
|
12055815 |
Block, sliding, lower |
|
Part No. |
Description |
|
A820202005521 |
Bushing |
|
A820601040420 |
Block, sliding, upper |
|
Part No. |
Description |
|
A210416000035 |
Ring, retaining |
|
A221500000141 |
Bearing, joint |
|
A210307000031 |
Nut M12GB6170 10 |
|
10424846 |
Plate, protective |
|
10424847 |
Cushion, protective |
|
A210204000021 |
Bolt M12x30 Cap Screw |
|
13243226 |
Assembly, cylinder barrel |
|
B230101001561 |
Seal, Dust |
|
11567379 |
Bearing, oilless |
|
60247455 |
Ring, seal |
|
60115011 |
Ring, seal, BS |
|
12298498 |
Ring, retaining |
|
B230101000428 |
Seal, Dust |
|
A880802010064 |
O-ring |
|
10424845 |
Ring, retaining |
|
A210609000260 |
O-ring |
|
10250757 |
Ring, Back-up |
|
13147815 |
Sleeve, guide |
|
11567377 |
Ring, retaining |
|
24004768 |
Screw |
|
A210401000006 |
Washer Lock M20 |
|
A210204000061 |
Screw |
