B220801000002 Gearbox

B220801000002 Gearbox

111 A210608000067 O-ring 1
112 10514233 Cap, oil filling 1
113 11325602 Filler, oil 1
114 11325635 Support 1
115 11597596 Hose, rubber 1
116 11597614 Hose, rubber 1
117 10268123 Support 2 2
118 A210405000001 Washer 6
119 10514234 Joint 1
120 11325590 Pipe,steel,oil filler 1
121 11597856 Kit, engine oil dipstick 1
122 A210404000003 Washer 2

1 60138966 Components, housing, gearbox 1
2 60138967 Components, rear cover and gearbox 1
3 60140031 Shaft, turbine 1
4 60138822 Group, gear, power input end 1
5 60139513 Components, hub 1
6 60138447 Components, transmission plate 1
7 60139867 Components, drive pump support 1
8 60139839 Shaft, transmission, grade 2 3 4, front wheel driving 1
9 60138844 Group, gear, speed-change, grade 1 1
10 60139838 Shaft, clutch, forward gear 1
11 60139893 Shaft, clutch, speed-change, grade 3 1
12 60138840 Group, gear, speed-change, grade 3 1
13 60139319 Components, shaft, backward gear 1
14 60138916 Components, clutch, speed-change, grade 1 1
15 60138934 Components, clutch shaft, grade 3 4 1
16 60139145 Components, idler shaft 1
17 60139925 Components, output shaft 1
18 60138682 Components, pressure adjusting valve and feeding pump 1
19 60138721 Components, electric adjusting valve 1
20 60139923 Components, flange, output end 1
21 60138442 Components, transporting cover 1
22 60138738 Valve, pressure adjusting 1

23 60138654 Pump, prefill 1
24 60138719 Valve, adjusting, prefill pump 1
25 60138733 Components, cover, control valve box 1
26 60138722 Components, electric control valve 1
27 60138891 Filter, dual 1
28 60140275 Package, sealing parts 1
29 60140286 Package, sealing parts, converter 1
