Body,container reach stacker, SRSC45H1 GRM





Item No.

Part No.

Description

Qty.

23

60236836

Adjuster, telescopic

1

24

60236837

Cap, steering wheel

1

25

60191992

Key, swith

2























Group 8 System, air conditioning


















Item No.

Part No.

Description

Qty.

1

60172546

Assembly, air conditioner

1

2

A210204000181

Screw

15

3

A210401000001

Washer

20

6

A230103000012

Hose, vapor

11

20

11783411

Support, left

1

21

11783412

Support, right

1


















Item No.

Part No.

Description

Qty.

4

A210307000017

Nut

15

9

A210111000081

Bolt

14

10

A210405000006

Washer

28

11

A210307000016

Nut

14

12

A210855000007

Hoop

6

13

60021998

Anchor ear, T-type

10

14

A210401000017

Washer

4

15

A210405000007

Washer

4

16

A210111000090

Bolt

4

17

12483146

Support, air compressor

1

18

A210111000027

Bolt

4

19

A210405000011

Washer

20


















Item No.

Part No.

Description

Qty.

2

A210204000181

Screw

15

3

A210401000001

Washer

20

4

A210307000017

Nut

15

5

21004569

Clamp

4

7

11815375

Duct, air, defrosting

1

8

11621235

Cover, guide wind

1

9

A210111000081

Bolt

14

10

A210405000006

Washer

28

11

A210307000016

Nut

14

22

11906229

Cover, guide wind

1


















Item No.

Part No.

Description

Qty.

1

60100865

GP, evaporator

1

2

60100916

Valve, lip

1

3

60174624

Compressor

1

4

60174750

Belt

1

5

60137511

Pipe, low pressure

1

6

60137517

Pipe, high pressure

1




















Item No.

Part No.

Description

Qty.

5

60137511

Pipe, low pressure

1

6

60137517

Pipe, high pressure

1

7

60137514

Pipe, high pressure

1

8

60137523

Assembly, condenser

1


















Item No.

Part No.

Description

Qty.

9

60137526

Assembly, liquid reservoir

1

10

60100917

Valve, hot water, electric

1

11

60137512

Pipe, high pressure

1

12

60100866

O-ring

2
